Motorola MTP85 0EX Series Basic Service Manual

5.5
Radio Disassembly and Reassembly
Mechanical checks and self-tests should be performed on the unit at the basic level of service.
NOTE: Read each procedure thoroughly before performing the actual task.
5.5.1
Torque Specification Chart
Use the recommended torque value in this chart when fastening different parts of the radio.
Table 17: Torques Specifications Chart
Description Part/Kit Quantity Torque
SIM door screw (M2) FN000114A01 2 Refer to
PD003153A02 for
Torque values.
5.5.2
Disassembling the Radio
Only Motorola Solutions Service Centers or Authorized Motorola Solutions Service Dealers can
disassemble the radio for repair or maintenance.
5.5.2.1
Removing the Antenna
Procedure:
Turn the antenna counter clockwise until it is detached from the radio.
MN002465A01-AN
Chapter 5 : Maintenance
57
