Motorola MTP85 0EX Series Basic Service Manual

1.3
TEDS Specifications
The radio has the capability for TETRA Enhanced Data Service (TEDS).
Tx Maximum Output Power
0.56 W
Modulation Type
4QAM
16QAM
64QAM
Channel Spacing
25 kHz
50 kHz
Table 14: TEDS Specifications
Channel Bandwidth Data Rate Receiver Sensitivity
25 kHz 38.4 kbit/s or less –109 dBm
38.5 kbit/s to 76.8 kbit/s –102 dBm
Greater than 76.8 kbit/s –97 dBm
50 kHz 76.8 kbit/s or less –106 dBm
76.9 kbit/s to 153.6 kbit/s –99 dBm
Greater than 153.6 kbit/s –93 dBm
MN002465A01-AN
Chapter 1 : Model Information
26
