• For 350–470 MHz radios, enter 30 for Max Tx Level. Press Enter.
• For 806–870 MHz radios, enter 30 (Class 4 radio) or 32.5 (Class 3L radio) for Max Tx Level.
Press Enter.
12 Enter -53 for Access Parameter. Press Enter.
13 Press CONFIG. Select Base Services.
NOTE: You are entering base services setup. The displayed value are factory defaults
and should not be changed.
Power On Registration: Required
Power Off De-registration: Required
Priority Cell: Yes
Minimum Mode Service: May Be Used
Migration: Supported
System Wide Services: Normal Mode
TETRA Voice Service: Supported
Circuit Mode Data Service: Supported
(Reserved): Available
TETRA Packet Data Service: Available
Air Interface Encryption: Not Available
Advanced Link: Not Supported
14 Press CONFIG. Select Neighbor Cell Info.
15 Verify that the following NEIGHBOUR CELL INFO values are displayed:
NOTE: The displayed values are factory defaults and should not be changed.
BROADCAST: Not Supported
BROADCAST INTERVAL: 5 s
NEIGHBOUR CELL CHANNEL: 8500
NEIGHBOUR CELL LOCATION AREA: 0017
NEIGHBOUR CELL IDENTIFIER: 01
SLOW RE-SELECT THRESHOLD ABOVE FAST: 10 dB
FAST RE-SELECT THRESHOLD: 10 dB
SLOW RE-SELECT HYSTERESIS: 10 dB
FAST RE-SELECT HYSTERESIS: 10 dB
16 Press CONFIG. Select Call Timers & Trunking.
17 Select Transmission for Trunking Type.
18 Select Continuous for Test Set Transmit Mode.
4.4
Configuring IFR 2968 Setup
Use these procedures to configure the IFR 2968 setup.
Procedure:
1 Turn ON the IFR.
2 Press Systems Mode Key and wait until the digital system is initialized.
3 Press Tetra Mobile→Setup. Enter the System Parameters Screen.
4 Press Channel Plan.
5 Perform one of the following actions:
• For 350–470 MHz, press Tetra 380+0MS.
The Control Channel automatically changes to 3600, and Traffic Channel automatically
changes to 3700.
MN002465A01-AN
Chapter 4 : Test Setup and Testing
36
