Motorola MTP85 0EX Series Basic Service Manual

Figure 18: Hand-Press Jig
Figure 19: Vertical Pressure to the Gore Membrane
1
4
3
2
Annotation Description
1 Seal port or gore membrane
2 Back chassis
3 Hand-press jig
4 Alignment and vertical pressure of the hand-press jig to the gore
membrane
5 Slide the back cover upwards along the grooves on the back chassis.
MN002465A01-AN
Chapter 5 : Maintenance
69
