Motorola MTP85 0EX Series Basic Service Manual

4.11.1
Testing in DALT Mode
NOTE: Any key pressed causes the test to advance from one step to the next. You are to
respond accordingly to the instructions on the screen.
Procedure:
Display Test
1 The display shows:
Display
Test
2 Do the following:
Action The display shows:
Press any key. Horizontal red lines.
Press any key consecutive-
ly.
Horizontal red lines become thicker with every key press,
until it becomes fully red.
Press any key. Four colored rectangles.
Press any key consecutive-
ly.
Vertical green lines that become thicker with every key
press, until it becomes fully green.
Press any key. White screen.
Press any key. Black screen.
Press any key. Blue screen and
END LCD test!!!
3 Press the corresponding key to proceed to the next test.
Battery Test
4 The display shows:
Battery
Test
5 Do the following:
Action The display shows:
Press any key. Battery
Interface Test
PASSED
6 Press the corresponding key to proceed to the next test.
SIM Card Test
7 The display shows:
SIM card
Test
8 Do the following:
Action Result
Press any key.
• If SIM card is detected in SIM slot, the display shows:
MN002465A01-AN
Chapter 4 : Test Setup and Testing
44
