Motorola MTP85 0EX Series Basic Service Manual

Action Result
SIM card
PASSED
Press Any key
To Continue
9 Press the corresponding key to proceed to the next test.
Vibrator Test
10 The display shows:
Vibrator
Test
11 Do the following:
Action Result
Press any key. The display shows:
Vibrator On
The radio vibrates.
12 Press the corresponding key to proceed to the next test.
LEDs Test
13 The display shows:
LEDs
Test
14 Do the following:
Action Result
Press any key. The display shows:
Red LED on
LED Status Indicator lights up in red.
Press any key. The display shows:
Green LED on
LED Status Indicator lights up in green.
Press any key. The display shows:
Amber LED on
LED Status Indicator lights up in amber.
Press any key. The display shows:
All LEDs on
LED on the top of the radio blinks in combination of red,
green, and amber.
15 Press the corresponding key to proceed to the next test.
Backlight Test
16 The display shows:
Backlight
Test
17 Do the following:
MN002465A01-AN
Chapter 4 : Test Setup and Testing
45
