Action Result
Press any key. The display shows:
Keypad
Backlight On
The radio keypad backlight lights up.
Press any key. The display shows:
Display
Backlight On
The radio display backlight lights up.
18 Press the corresponding key to proceed to the next test.
MACE Test
19 The display shows:
MACE
Press Any key
To Continue
20 Do the following:
Action Result
Press any key.
• If Micro HSM card is detected in SD slot, the display
shows:
MACE ping
test PASSED
Press Any key
To Continue
• If Micro HSM card is not detected in SD slot, the display
shows:
MACE ping
test FAILED
Press Any key
To Continue
21 Press the corresponding key to proceed to the next test.
Accessory Connect Test
22 The display shows:
Accessory
Connect Test
23 Do the following:
Action Result
Press any key. The display shows:
Connect GCAI
1. Core Accy
2. IMPRES Accy
to the radio
and press any key
Attach Core or IMPRES ac-
cessory to the SLIM connec-
tor.
Core RSM connected or IMPRES RSM
PMMNxxxx connected
MN002465A01-AN
Chapter 4 : Test Setup and Testing
46
