Motorola MTP85 0EX Series Basic Service Manual

Figure 8: Dust Cover Removal
1
2
Annotation Description
1 Dust cover
2 Thumb screw
5.5.2.4
Removing the Back Cover Identifcation Kit
Procedure:
1 Using your finger, slide the back cover identification kit downwards from either left or right side.
2 Once one of the side is detached, slide the other side to fully remove the back cover
identification kit from the back chassis.
MN002465A01-AN
Chapter 5 : Maintenance
60
