Motorola MTP85 0EX Series Basic Service Manual

Test Name Test Setup Radio Setup Test Conditions Limits
Time Slot N/A 3 N/A
Country Code N/A 234 N/A
Network Code N/A 2392 N/A
Base Color N/A 1 N/A
Location Area N/A 22 N/A
Min Rx Level N/A N/A –110 dBm
Max Tx Level N/A N/A 30 dBm (Class
4)
32.5 dBm (Class
3L)
Access Parame-
ter
N/A –53 dBm N/A
Mobile Power 30 dBm (Class
4)
32.5 dBm (Class
3L)
N/A N/A
Burst Type N/A Normal N/A
Transmitter
Burst Power
RF Gen Level
Burst Power
N/A –90 dBm 28–32 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
Timing Error N/A N/A ±0.25 Symbols
Vector Error N/A N/A Max 10% RMS,
30% Peak
Frequency Error N/A N/A ±100 Hz
Call Processing
Talk Back
1 kHz Test Sig-
nal Group Mode
N/A –50 dBm N/A
Call Processing
Call to Mobile
Private 4 digit random
number and
Send
N/A 28–32 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
RF Gen Level
Burst Power
N/A –90 dBm 28–32 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
Timing Error N/A N/A ±0.25 Symbols
Vector Error N/A N/A Max 10% RMS,
30% Peak
Frequency Error N/A N/A ±100 Hz
MN002465A01-AN
Chapter 4 : Test Setup and Testing
34
