Controller T6/T7 Schematics and Parts Lists (8471235L06)) Section 3: 3-63
6881091C63-F
C0508 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0509 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0510 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0511 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0512 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0513 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0514 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0515 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0516 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0517 2113944A38 CAP CER CHP 82.0PF 50V 5%
C0518 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0541 2313960A55 CAP,FXD,.47UF,+10%,-
10%,25V-DC,SM,-55DEG
CMIN,125DEG CMAX,73MA
C0542 2313960F30 CAP,FXD,47UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,303MA
C0560 2113945A09 CAP CER CHP 1000PF 50V
10%
C0591 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0592 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0593 2113945H69 CAP,FXD,.1UF,+5%,-5%,50V-
DC,1206,X7R,-55DEG
CMIN,125DEG CMAX,PB
C0601 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0603 2389289U01 10UF 50V 20, ALUMINUM SMD
Circuit
Ref
Motorola
Part No.
Description
C0611 2314030J28 CAP,FXD,22UF,+10%,-
10%,35V-DC,SM,-55DEG
CMIN,125DEG CMAX,742MA
C0612 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0622 2313960F30 CAP,FXD,47UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,303MA
C0641 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0644 2313960F04 CAP,FXD,33UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,303MA
C0645 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0652 2313960F04 CAP,FXD,33UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,303MA
C0654 2313960D07 CAP,FXD,10UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,174MA
C0655 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0661 2314030H05 CAP,FXD,47UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,866MA
C0662 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0663 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0671 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0681 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
D0101 4813974A05 DIODE,SWG,MMBD301,SM,SO
T-23,30V,.2W,SHTK,PB-FREE
D0151 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
D0179 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
D0621 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
D0651 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
Circuit
Ref
Motorola
Part No.
Description
D0660 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
D0661 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
E0271 2415954H02 INDUCTOR BEAD CHIP EPP
WITH EPOXY
E0272 2415954H02 INDUCTOR BEAD CHIP EPP
WITH EPOXY
E0273 2415954H02 INDUCTOR BEAD CHIP EPP
WITH EPOXY
E0631 2415954H02 INDUCTOR BEAD CHIP EPP
WITH EPOXY
F0401 6515076H01 FUSE CHIP SMT TR/1608FF 3A
J0401 0916162H02 12 POS, FLEX CONNECTOR,
SIDE ENTRY
J0451 0916162H01 18 POS, FLEX CONNECTOR,
SIDE ENTRY
J0501 0966512A01 20 POS. 0,64 SQ CONNECTOR
J0551 0915064H03 CONNECTOR, ZIF (40 PINS)
J0552 0915064H01 ZIF (18 PINS)
J0601 0986165B05 DC POWER CONNECTOR
Q0110 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0151 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0171 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0173 4816147H01 TSTR NPN DRLNGTN MXTA27
Q0177 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0181 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0183 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0185 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0271 4813973M07 XSTR,BIP GP
SS,NPN,T3904,SM,SOT-
23,SMT,40V,.225W,200MA,300
MHZ
Q0641 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0661 4816097H01 XISTOR FMC2 RH
Circuit
Ref
Motorola
Part No.
Description
Q0662 4813973M07 XSTR,BIP GP
SS,NPN,T3904,SM,SOT-
23,SMT,40V,.225W,200MA,300
MHZ
Q0663 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q0681 4816147H01 TSTR NPN DRLNGTN MXTA27
R0101 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0102 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0103 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R0104 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0105 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0108 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R0111 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R0113 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0114 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0115 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0117 0613952H87 CER CHIP RES 3900 OHM 5%
0603
R0121 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0131 0613952J73 CER CHIP RES 10.0M OHM 5%
0603
R0132 0613952J37 CER CHIP RES 330K OHM 5%
0603
R0151 0613952J10 CER CHIP RES 24K OHM 5
0603
R0152 0613952J10 CER CHIP RES 24K OHM 5
0603
R0170 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0171 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0172 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0173 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0174 0613952J01 CER CHIP RES 10K OHM 5%
0603
Circuit
Ref
Motorola
Part No.
Description
To Next Page
