Section 3: 3-64 Controller T6/T7 Schematics and Parts Lists (8471235L06))
6881091C63-F
R0175 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0176 0613952J12 CER CHIP RES 30K OHM 5
0603
R0177 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0178 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0179 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0181 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0182 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0183 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0184 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0185 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0186 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0201 0613952H49 CER CHIP RES 100 OHM 5%
0603
R0202 0613952H67 CER CHIP RES 560 OHM 5
0603
R0203 0613952H49 CER CHIP RES 100 OHM 5%
0603
R0204 0613952H67 CER CHIP RES 560 OHM 5
0603
R0205 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0206 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0207 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R0208 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R0211 0613958D85 CER CHIP RES 7500 OHM 1%
0805
R0212 0613958D85 CER CHIP RES 7500 OHM 1%
0805
R0221 0613952J10 CER CHIP RES 24K OHM 5
0603
R0222 0613952J10 CER CHIP RES 24K OHM 5
0603
R0223 0613952J12 CER CHIP RES 30K OHM 5
0603
R0224 0613952H95 CER CHIP RES 8200 OHM 5
0603
Circuit
Ref
Motorola
Part No.
Description
R0229 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R0241 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0242 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R0251 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0252 0613952J19 CER CHIP RES 56K OHM 5%
0603
R0253 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0254 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0255 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0256 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0257 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R0261 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0262 0613952J35 CER CHIP RES 270K OHM 5%
0603
R0265 0613952J10 CER CHIP RES 24K OHM 5
0603
R0267 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0268 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0269 0613952H65 CER CHIP RES 470 OHM 5%
0603
R0273 0613952J10 CER CHIP RES 24K OHM 5
0603
R0275 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0276 0613952J05 CER CHIP RES 15K OHM 5%
0603
R0401 0613952H57 CER CHIP RES 220 OHM 5%
0603
R0407 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R0408 0613952H49 CER CHIP RES 100 OHM 5%
0603
R0409 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R0412 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R0441 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
Circuit
Ref
Motorola
Part No.
Description
R0442 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R0467 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R0468 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0481 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R0482 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R0510 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0511 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0512 0613952J05 CER CHIP RES 15K OHM 5%
0603
R0525 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0529 0613952J17 CER CHIP RES 47K OHM 5%
0603
R0530 0613952J09 CER CHIP RES 22K OHM 5%
0603
R0531 0613952H67 CER CHIP RES 560 OHM 5
0603
R0533 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R0535 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R0537 0613952H57 CER CHIP RES 220 OHM 5%
0603
R0538 0613952H57 CER CHIP RES 220 OHM 5%
0603
R0539 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0541 0613952J11 CER CHIP RES 27K OHM 5%
0603
R0543 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0555 0613952H49 CER CHIP RES 100 OHM 5%
0603
R0556 0613952H49 CER CHIP RES 100 OHM 5%
0603
R0591 0613952J10 CER CHIP RES 24K OHM 5
0603
R0592 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R0593 0613952J25 CER CHIP RES 100K OHM 5%
0603
R0611 0613952J19 CER CHIP RES 56K OHM 5%
0603
Circuit
Ref
Motorola
Part No.
Description
R0612 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R0621 0613952J10 CER CHIP RES 24K OHM 5
0603
R0641 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0642 0613958D85 CER CHIP RES 7500 OHM 1%
0805
R0643 0613958D09 CER CHIP RES 1210 OHM 1%
0805
R0651 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R0652 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R0661 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R0662 0613952J29 CER CHIP RES 150K OHM 5%
0603
R0671 0613952J12 CER CHIP RES 30K OHM 5
0603
R0672 0613952J01 CER CHIP RES 10K OHM 5%
0603
R0681 0613952J07 CER CHIP RES 18K OHM 5%
0603
R0682 0613952J21 CER CHIP RES 68K OHM 5%
0603
U0101 5.19E+09 HC11FL0 (3V) ASIC MICRO-P
U0111 5116648H01 128KBIT SERIAL SPI BUS
EEPROM
U0121 51012083001 IC FLASH 4MBIT 5V 8MM20MM
U0122 5116096H01 32K X 8 SRAM 28PIN TSOP
U0141 5114000A14 IC,DECODER/DEMUX,1PER
PKG,74HC138,SM,SOIC16,PB-
FREE
U0211 5114016A18 IC,OP AMP,4PER
PKG,GP,SOIC,PB FREE
U0221 5115062H01 IC ASFIC_CMP
U0251 5114002A17 IC,MUX/
DEMUX,MC14053BD,SM,SOIC
16,3PER PKG,2CHANNELS,2
CHANNEL,P
U0271 5102463J95 AUDIO PA TDA1519C
U0611 5164015H94 IC, LM2941, TO DROPOUT
REG
U0641 5164015H94 IC, LM2941, TO DROPOUT
REG
U0651 5114014A07 IC,LNR V
REGLTR,FXD,5V,500MA,SM,D
PAK,PB-FREE
Circuit
Ref
Motorola
Part No.
Description
