VHF (136–174 MHz) 1–25 W PCB 8471235L06 Schematics, and Parts Lists Section 4: 4-55
6881091C63-F
C3231 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3232 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3233 2313960B28 CAP,FXD,2.2UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,104MA
C3234 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3235 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3242 2113944C02 CAP CER CHP 220.0PF 50V 5%
C3243 2113944C02 CAP CER CHP 220.0PF 50V 5%
C3244 2113944C02 CAP CER CHP 220.0PF 50V 5%
C3245 2113944C02 CAP CER CHP 220.0PF 50V 5%
C3246 2113944C02 CAP CER CHP 220.0PF 50V 5%
C3247 2113944C30 CAP CER CHP 10.0PF 50V +/-
0.5PF
C3251 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3252 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3253 2313960B30 CAP,FXD,4.7UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,122MA
C3254 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3255 2313960B28 CAP,FXD,2.2UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,104MA
C3263 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3302 2113944C73 CAP,FXD,6.8PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3303 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3306 2113944C70 CAP,FXD,5.1PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3311 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3314 2113944C73 CAP,FXD,6.8PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3315 2113944C32 CAP CER CHP 15.0PF 50V 5%
Circuit
Ref
Motorola
Part No.
Description
C3316 2113944C18 CAP CER CHP 3.3PF 50V +/-
0.25PF
C3317 2113944C36 CAP CER CHP 33.0PF 50V 5%
C3318 2113944C71 CAP,FXD,5.6PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3319 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3324 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3332 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3333 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3334 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3335 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3336 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3337 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3341 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3342 2113944M05 CAP,FXD,3PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C3344 2113944C69 CAP,FXD,1.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3345 2113944M25 CAP,FXD,20PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C3346 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3347 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3348 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3351 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3352 2113945C04 CAP CER CHP 22,000PF 50V
10%
Circuit
Ref
Motorola
Part No.
Description
C3355 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3356 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3357 2113944C74 CAP,FXD,7.5PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3361 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3362 2113944C71 CAP,FXD,5.6PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3363 2113944C41 CAP CER CHP 68.0PF 50V 5%
C3364 2113944C32 CAP CER CHP 15.0PF 50V 5%
C3365 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3400 2113944C04 CAP CER CHP 330.0PF 50V 5%
C3401 2113944C04 CAP CER CHP 330.0PF 50V 5%
C3402 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3403 2113944C36 CAP CER CHP 33.0PF 50V 5%
C3404 2113944C36 CAP CER CHP 33.0PF 50V 5%
C3405 2113944C06 CAP CER CHP 470.0PF 50V 5%
C3406 2113944C06 CAP CER CHP 470.0PF 50V 5%
C3410 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3411 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3412 2113944C04 CAP CER CHP 330.0PF 50V 5%
C3413 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3414 2113944C04 CAP CER CHP 330.0PF 50V 5%
C3415 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3416 2113944C04 CAP CER CHP 330.0PF 50V 5%
C3417 2113944C38 CAP CER CHP 56.0PF 50V
5%CAP CER CHP 47.0PF 50V
5%
C3418 2113944C36 CAP CER CHP 33.0PF 50V 5%
C3419 2113944C04 CAP CER CHP 330.0PF 50V 5%
C3420 2113944C04 CAP CER CHP 330.0PF 50V 5%
C3421 2113945G57 CAP,FXD,.033UF,+5%,-5%,50V-
DC,0805,X7R,-55DEG
CMIN,125DEG CMAX
C3422 2113944F04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C3423 2313960C26 CAP,FXD,1UF,+10%,-10%,35V-
DC,SM,-55DEG CMIN,125DEG
CMAX,114MA,E
C3424 2113944C06 CAP CER CHP 470.0PF 50V 5%
Circuit
Ref
Motorola
Part No.
Description
C3425 2113945C25 CAP,FXD,.033UF,+10%,-
10%,50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C3426 2113944C04 CAP CER CHP 330.0PF 50V 5%
C3427 2113945L37 CAP,FXD,3300PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3428 2113945L33 CAP,FXD,2200PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3431 2111078B34 CAP CHIP RF 47 5 NPO 100V
C3433 2111078B36 CAP CHIP RF 56 5 NPO 100V
C3434 2113945G45 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0805,X7R,-55DEG
CMIN,125DEG CMAX,P
C3435 2113944F04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C3436 2313960G32 CAP,FXD,10UF,+10%,-10%,35V-
DC,SM,-55DEG CMIN,125DEG
CMAX,387MA
C3437 2113945G57 CAP,FXD,.033UF,+5%,-5%,50V-
DC,0805,X7R,-55DEG
CMIN,125DEG CMAX
C3438 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3439 2111078B59 CAP CHIP RF 470 5 NPO 100V
C3440 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3441 2111078B47 CAP CHIP RF 150 5 NPO 100V
C3442 2111078B47 CAP CHIP RF 150 5 NPO 100V
C3444 2111078B36 CAP CHIP RF 56 5 NPO 100V
C3445 2111078B23 CAP CHIP RF 24 5 NPO 100V
C3446 2111078B37 CAP CHIP RF 62 5 NPO 100V
C3447 2111078B19 CAP CHIP RF 16 5 NPO 100V
C3450 2113944C06 CAP CER CHP 470.0PF 50V 5%
C3451 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3452 2113944C31 CAP CER CHP 12.0PF 50V 5%
C3453 2113944C06 CAP CER CHP 470.0PF 50V 5%
C3471 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3472 2111078B53 CAP CHIP RF 270 5 NPO 100V
C3473 2111078B53 CAP CHIP RF 270 5 NPO 100V
C3474 2113944C02 CAP CER CHP 220.0PF 50V 5%
C3475 2113944C73 CAP,FXD,6.8PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3491 2111078B18 CAP CHIP RF 15 5 NPO 100V
C3492 2111078B38 CAP CHIP RF 68 5 NPO 100V
C3493 2111078B08 CAP CHIP RF 6.2 .25 NPO 100V
C3494 2111078B16 CAP CHIP RF 13 5 NPO 100V
C3495 2111078B01 CAP CHIP RF 3.3 .25 NPO 100V
C3496 2111078B31 CAP CHIP RF 36 5 NPO 100V
C3498 2111078B16 CAP CHIP RF 13 5 NPO 100V
Circuit
Ref
Motorola
Part No.
Description
