Section 4: 4-56 VHF (136–174 MHz) 1–25 W PCB 8471235L06 Schematics, and Parts Lists
6881091C63-F
C3499 2111078B19 CAP CHIP RF 16 5 NPO 100V
C3501 2113945L33 CAP,FXD,2200PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3502 2113945L37 CAP,FXD,3300PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3503 2113944C06 CAP CER CHP 470.0PF 50V 5%
C3504 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3505 2313960B01 CAP,FXD,1UF,+10%,-10%,16V-
DC,SM,-55DEG CMIN,125DEG
CMAX,87MA,E
C3506 2113945L33 CAP,FXD,2200PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3507 2113944C45 CAP CER CHP 100.0PF 50V 5%
C3508 2113944C06 CAP CER CHP 470.0PF 50V 5%
C3510 2113945L37 CAP,FXD,3300PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
D3000 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
D3001 4885094Y01 DIODE VARACTOR ISV228
W18
D3003 4813974A17 DIODE ARRAY,MXR,SM,SOT-
23,7V,.225W,SHTK,2,HOT CAR-
RIER, PB-FREE
D3004 4885094Y01 DIODE VARACTOR ISV228
W18
D3011 4813974A06 DIODE,PIN,SM,SOT-
23,35V,.2W,SLCN,PB-FREE
D3031 4886143B01 WM MIXER QUAD RING DIODE
D3101 4813974A17 DIODE ARRAY,MXR,SM,SOT-
23,7V,.225W,SHTK,2,HOT CAR-
RIER, PB-FREE
D3201 4815011H01 DIODE TRIPLE
D3221 4813974A05 DIODE,SWG,MMBD301,SM,SO
T-23,30V,.2W,SHTK,PB-FREE
D3341 4885094Y01 DIODE VARACTOR ISV228
W18
D3361 4885094Y01 DIODE VARACTOR ISV228
W18
D3362 4885055Y01 DIODE VARACTOR PB-FREE
D3401 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
D3451 4813974A05 DIODE,SWG,MMBD301,SM,SO
T-23,30V,.2W,SHTK,PB-FREE
D3471 4802482J02 PIN DIODE SMD
D3472 4802482J02 PIN DIODE SMD
FL3101 9180112R16 44.85 MHZ CRYSTAL FILTER
FL3102 9180112R16 44.85 MHZ CRYSTAL FILTER
FL3111 9115811H01 SMD455KHZ 6 ELEMENT
FL3112 9115811H04 SMD455KHZ 6 ELEMENT
Circuit
Ref
Motorola
Part No.
Description
FL3113 9180468V04 SMD455KHZ 4 ELEMENT CER
FLTR
FL3114 9180468V06 SMD455KHZ 4 ELEMENT CER
FLTR
J3401 0986166B01 MOBILE RF CONNECTOR
(BNC)
L3002 2414032D23 IDCTR,WW,470NH,5%,490MA,1
.3OHM,CER,33Q,480MHZSRF,S
M,LEAD-FR
L3031 2414032D24 IDCTR,WW,560NH,5%,460MA,1
.34OHM,CER,30 Q,440MHZ
SRF,SM,PB-F
L3032 2414032D17 IDCTR,WW,150NH,5%,750MA,.
31OHM,CER,40 Q,850MHZ
SRF,SM,PB-FR
L3101 2414032D25 IDCTR,WW,620NH,5%,400MA,1
.6OHM,CER,28 Q,400MHZ
SRF,SM,PB-FR
L3111 2414032D25 IDCTR,WW,620NH,5%,400MA,1
.6OHM,CER,28 Q,400MHZ
SRF,SM,PB-FR
L3112 2414032D25 IDCTR,WW,620NH,5%,400MA,1
.6OHM,CER,28 Q,400MHZ
SRF,SM,PB-FR
L3124 2414032B68 IDCTR,WW,1UH,5%,460MA,1.7
5OHM,CER,33 Q,290MHZ
SRF,SM,PB-FRE
L3201 2414017Q42 IDCTR,FXD,390NH,10%,200MA
,.65OHM,FERR,25 Q,135MHZ
SRF,SM,080
L3231 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,.
65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L3301 2414032B44 IDCTR,WW,18NH,5%,1A,.11OH
M,CER,50 Q,2.5GHZ
SRF,SM,PB-FREE
L3302 2414032B53 IDCTR,WW,100NH,5%,800MA,.
56OHM,CER,25 Q,950MHZ
SRF,SM,PB-FR
L3317 2414032F28 IDCTR,WW,33NH,5%,500MA,.2
7OHM,CER,40 Q,1.8GHZ
SRF,SM,PB-FRE
L3318 2414032F34 IDCTR,WW,100NH,5%,400MA,.
46OHM,CER,40 Q,950MHZ
SRF,SM,PB-FR
L3331 2414032F32 IDCTR,FXD,68NH,5%,500MA,.3
8OHM,CER,40 Q,1.2GHZ
SRF,SM,0805,P
L3332 2414032F15 IDCTR,WW,100NH,10%,400MA,
.46OHM,CER,40 Q,950MHZ
SRF,SM,PB-F
L3333 2414017Q47 IDCTR,FXD,1UH,10%,50MA,.45
OHM,FERR,45 Q,75MHZ
SRF,SM,0805,PB
L3341 2415385H01 8 NH MINISPRING AIR CORE
INDUCTOR
Circuit
Ref
Motorola
Part No.
Description
L3343 2414032B56 IDCTR,WW,180NH,5%,750MA,.
77OHM,CER,25 Q,700MHZ
SRF,SM,PB-FR
L3344 2414032B68 IDCTR,WW,1UH,5%,460MA,1.7
5OHM,CER,33 Q,290MHZ
SRF,SM,PB-FRE
L3345 2414032B68 IDCTR,WW,1UH,5%,460MA,1.7
5OHM,CER,33 Q,290MHZ
SRF,SM,PB-FRE
L3346 2415385H07 COIL SURFACE MOUNT AIR
WOUND
L3351 2414032B68 IDCTR,WW,1UH,5%,460MA,1.7
5OHM,CER,33 Q,290MHZ
SRF,SM,PB-FRE
L3361 2414032B50 IDCTR,WW,56NH,5%,1A,.18OH
M,CER,50 Q,1.15GHZ
SRF,SM,PB-FREE
L3362 2414032B51 IDCTR,WW,68NH,5%,1A,.2OHM
,CER,50 Q,1.05GHZ
SRF,SM,PB-FREE
L3363 2414032B50 IDCTR,WW,56NH,5%,1A,.18OH
M,CER,50 Q,1.15GHZ
SRF,SM,PB-FREE
L3364 2414032B68 IDCTR,WW,1UH,5%,460MA,1.7
5OHM,CER,33 Q,290MHZ
SRF,SM,PB-FRE
L3401 2460591A01 COIL AIR WOUND INDUC 4.22
L3402 2415954H02 INDUCTOR BEAD CHIP EPP
WITH EPOXY
L3403 2414032D13 IDCTR,WW,68NH,5%,900MA,.2
6OHM,CER,42 Q,1.08GHZ
SRF,SM,PB-FR
L3411 2414032D13 IDCTR,WW,68NH,5%,900MA,.2
6OHM,CER,42 Q,1.08GHZ
SRF,SM,PB-FR
L3412 2414032B42 IDCTR,WW,12NH,5%,1A,.09OH
M,CER,50 Q,3GHZ SRF,SM,PB-
FREE
L3414 2460591A11 COIL AIR WOUND INDUC 7.66
L3421 2415954H02 INDUCTOR BEAD CHIP EPP
WITH EPOXY
L3422 2460591C23 COIL AIR WOUND INDUC 13.85
L3436 2415954H02 INDUCTOR BEAD CHIP EPP
WITH EPOXY
L3437 2460592A01 COIL AW 2 TURN 17 NH
L3443 2460591X02 COIL AIR WOUND SQUARE 4
TURNS
L3471 2414032B69 IDCTR,WW,1.2UH,5%,440MA,2
OHM,CER,20 Q,200MHZ
SRF,SM,PB-FREE
L3472 2460592B01 COIL AW 4 TURN 51 NH
L3491 2460592B01 COIL AW 4 TURN 51 NH
L3492 2460592B01 COIL AW 4 TURN 51 NH
L3493 2460592B01 COIL AW 4 TURN 51 NH
M3421 2686201B02 HEATSPREADER
Q3001 4802197J95 RF TRANSISTOR PBR941
Circuit
Ref
Motorola
Part No.
Description
Q3002 4813973A13 XSTR,GEN PURPOSE SMALL
SIG,PNP,MMBT3906L,TO-
236,4, PB-FREE
Q3021 4816097H01 XISTOR FMC2 RH
Q3101 4802197J95 RF TRANSISTOR PBR941
Q3102 4802197J95 RF TRANSISTOR PBR941
Q3141 4813973M07 XSTR,BIP GP
SS,NPN,T3904,SM,SOT-
23,SMT,40V,.225W,200MA,300M
HZ
Q3151 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q3152 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q3221 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q3301 4802197J95 RF TRANSISTOR PBR941
Q3303 4815055H01 TSTR DUAL NPN/PNP UMH 5
Q3304 4805218N63 RF TRANS SOT 323 BFQ67W
Q3411 4816097H01 XISTOR FMC2 RH
Q3421 4813976A04 FET RF 520MHZ 8W 12.5V
PLD-1.5 T&R
Q3422 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q3441 48012035001 LD MOS SMT 55W 175MHZ 12V
Q3442 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q3471 4813973A42 XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
Q3472 4816049H01 MEDIUM PWR TRANSISTOR
Q4451 4813973M07 XSTR,BIP GP
SS,NPN,T3904,SM,SOT-
23,SMT,40V,.225W,200MA,300M
HZ
R3000 0613952H77 CER CHIP RES 1500 OHM 5%
0603
R3001 0613952J25 CER CHIP RES 100K OHM 5%
0603
R3002 0613952H67 CER CHIP RES 560 OHM 5
0603
R3003 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R3004 0613952H77 CER CHIP RES 1500 OHM 5%
0603
R3006 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3009 0613952J25 CER CHIP RES 100K OHM 5%
0603
R3010 0613952H69 CER CHIP RES 680 OHM 5
0603
Circuit
Ref
Motorola
Part No.
Description
