Motorola Pro3100 Detailed Service Manual

VHF (136–174 MHz) 1–25 W PCB 8471235L06 Schematics, and Parts Lists Section 4: 4-57
6881091C63-F
R3011 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R3012 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R3013 0613952H85 CER CHIP RES 3300 OHM 5%
0603
R3014 0613952H42 CER CHIP RES 51.0 OHM 5%
0603
R3015 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R3016 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R3018 0613952H57 CER CHIP RES 220 OHM 5%
0603
R3019 0613952J17 CER CHIP RES 47K OHM 5%
0603
R3021 0613952H67 CER CHIP RES 560 OHM 5
0603
R3024 0613952H63 CER CHIP RES 390 OHM 5
0603
R3025 0613952H77 CER CHIP RES 1500 OHM 5%
0603
R3026 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3027 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3028 0613952H63 CER CHIP RES 390 OHM 5
0603
R3031 0613952H42 CER CHIP RES 51.0 OHM 5%
0603
R3033 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R3101 0613952J03 CER CHIP RES 12K OHM 5%
0603
R3102 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R3105 0613952H49 CER CHIP RES 100 OHM 5%
0603
R3106 0613952J11 CER CHIP RES 27K OHM 5%
0603
R3107 0613952H82 CER CHIP RES 2400 OHM 5
0603
R3108 0613952H75 CER CHIP RES 1200 OHM 5
0603
R3111 0613952J03 CER CHIP RES 12K OHM 5%
0603
R3112 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R3113 0613952H61 CER CHIP RES 330 OHM 5
0603
R3115 0613952H63 CER CHIP RES 390 OHM 5
0603
R3116 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R3117 0613952J11 CER CHIP RES 27K OHM 5%
0603
Circuit
Ref
Motorola
Part No.
Description
R3118 0613952H82 CER CHIP RES 2400 OHM 5
0603
R3124 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R3130 0613952H42 CER CHIP RES 51.0 OHM 5%
0603
R3132 0613952J05 CER CHIP RES 15K OHM 5%
0603
R3133 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R3134 0613952H95 CER CHIP RES 8200 OHM 5
0603
R3135 0613952H75 CER CHIP RES 1200 OHM 5
0603
R3141 0613952H63 CER CHIP RES 390 OHM 5
0603
R3142 0613952H79 CER CHIP RES 1800 OHM 5%
0603
R3144 0613952H82 CER CHIP RES 2400 OHM 5
0603
R3145 0613952H85 CER CHIP RES 3300 OHM 5%
0603
R3146 0613952H69 CER CHIP RES 680 OHM 5
0603
R3147 0613952J03 CER CHIP RES 12K OHM 5%
0603
R3151 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3152 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3153 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3154 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3201 0613952H41 CER CHIP RES 47.0 OHM 5
0603
R3203 0613952H41 CER CHIP RES 47.0 OHM 5
0603
R3204 0613952H41 CER CHIP RES 47.0 OHM 5
0603
R3211 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R3221 0613952H63 CER CHIP RES 390 OHM 5
0603
R3222 0613952H69 CER CHIP RES 680 OHM 5
0603
R3223 0613952H49 CER CHIP RES 100 OHM 5%
0603
R3224 0613952J17 CER CHIP RES 47K OHM 5%
0603
R3225 0613952J17 CER CHIP RES 47K OHM 5%
0603
R3227 0613952J25 CER CHIP RES 100K OHM 5%
0603
R3241 0613952H49 CER CHIP RES 100 OHM 5%
0603
Circuit
Ref
Motorola
Part No.
Description
R3242 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R3251 0613952J31 CER CHIP RES 180K OHM 5%
0603
R3252 0613952J37 CER CHIP RES 330K OHM 5%
0603
R3261 0613952J17 CER CHIP RES 47K OHM 5%
0603
R3263 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R3301 0613952H46 CER CHIP RES 75.0 OHM 5
0603
R3302 0613952H49 CER CHIP RES 100 OHM 5%
0603
R3303 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R3304 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R3308 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R3311 0613952H49 CER CHIP RES 100 OHM 5%
0603
R3316 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R3318 0613952H33 CER CHIP RES 22.0 OHM 5%
0603
R3321 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3323 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R3331 0613952H41 CER CHIP RES 47.0 OHM 5
0603
R3335 0613952H37 CER CHIP RES 33.0 OHM 5%
0603
R3336 0613952J05 CER CHIP RES 15K OHM 5%
0603
R3341 0613952H57 CER CHIP RES 220 OHM 5%
0603
R3342 0613952H39 CER CHIP RES 39.0 OHM 5%
0603
R3343 0613952H49 CER CHIP RES 100 OHM 5%
0603
R3351 0613952J08 CER CHIP RES 20K OHM 5
0603
R3352 0613952J03 CER CHIP RES 12K OHM 5%
0603
R3353 0613952J25 CER CHIP RES 100K OHM 5%
0603
R3354 0613952J29 CER CHIP RES 150K OHM 5%
0603
R3355 0613952J08 CER CHIP RES 20K OHM 5
0603
R3356 0613952J03 CER CHIP RES 12K OHM 5%
0603
R3361 0613952H57 CER CHIP RES 220 OHM 5%
0603
Circuit
Ref
Motorola
Part No.
Description
R3362 0613952H41 CER CHIP RES 47.0 OHM 5
0603
R3364 0613952J17 CER CHIP RES 47K OHM 5%
0603
R3400 0613952H65 CER CHIP RES 470 OHM 5%
0603
R3401 0613952H60 CER CHIP RES 300 OHM 5
0603
R3402 0613952H29 CER CHIP RES 15.0 OHM 5
0603
R3403 0613952H60 CER CHIP RES 300 OHM 5
0603
R3404 0613952J17 CER CHIP RES 47K OHM 5%
0603
R3405 0613952H49 CER CHIP RES 100 OHM 5%
0603
R3406 0613952J25 CER CHIP RES 100K OHM 5%
0603
R3407 0613958H18 CER CHIP RES 5.1 OHM 5%
0805
R3411 0613952H70 CER CHIP RES 750 OHM 5
0603
R3412 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R3413 0613952H85 CER CHIP RES 3300 OHM 5%
0603
R3414 0613959Y51 CER CHIP RES OHM 5% 2512
R3415 0613952H38 CER CHIP RES 36.0 OHM 5
0603
R3416 0613952H38 CER CHIP RES 36.0 OHM 5
0603
R3418 0613952J09 CER CHIP RES 22K OHM 5%
0603
R3421 0613952J15 CER CHIP RES 39K OHM 5%
0603
R3422 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R3423 0613952J15 CER CHIP RES 39K OHM 5%
0603
R3424 0613958H11 CER CHIP RES 2.7 OHM 5%
0805
R3425 0613958H11 CER CHIP RES 2.7 OHM 5%
0805
R3426 0613958H11 CER CHIP RES 2.7 OHM 5%
0805
R3427 0613958H11 CER CHIP RES 2.7 OHM 5%
0805
R3428 0613952H82 CER CHIP RES 2400 OHM 5
0603
R3429 0613952H57 CER CHIP RES 220 OHM 5%
0603
R3431 0613959Y42 CER CHIP RES OHM 5% 2512
R3432 0613959Y42 CER CHIP RES OHM 5% 2512
R3433 0613958H11 CER CHIP RES 2.7 OHM 5%
0805
Circuit
Ref
Motorola
Part No.
Description
