Motorola Pro3100 Detailed Service Manual

Section 4: 4-58 VHF (136–174 MHz) 1–25 W PCB 8471235L06 Schematics, and Parts Lists
6881091C63-F
R3434 0613958H11 CER CHIP RES 2.7 OHM 5%
0805
R3435 0613958H11 CER CHIP RES 2.7 OHM 5%
0805
R3441 0613952J15 CER CHIP RES 39K OHM 5%
0603
R3442 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R3443 0613952J15 CER CHIP RES 39K OHM 5%
0603
R3444 0613958H17 CER CHIP RES 4.7 OHM 5%
0805
R3445 0613952H82 CER CHIP RES 2400 OHM 5
0603
R3446 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R3450 0613952H65 CER CHIP RES 470 OHM 5%
0603
R3452 0613952J03 CER CHIP RES 12K OHM 5%
0603
R3454 0613952J12 CER CHIP RES 30K OHM 5
0603
R3455 0613952J25 CER CHIP RES 100K OHM 5%
0603
R3457 0613959Y51 CER CHIP RES OHM 5% 2512
R3471 0613952H65 CER CHIP RES 470 OHM 5%
0603
R3473 0613959Y42 CER CHIP RES OHM 5% 2512
R3474 0613959Y42 CER CHIP RES OHM 5% 2512
R3475 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3491 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3492 2415347H01 IDCTR, 1UH
R3501 0613952H93 CER CHIP RES 6800 OHM 5%
0603
R3502 0613952J15 CER CHIP RES 39K OHM 5%
0603
R3504 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3505 0613952J36 CER CHIP RES 300K OHM 5
0603
R3507 0613952J08 CER CHIP RES 20K OHM 5
0603
R3508 0613952J25 CER CHIP RES 100K OHM 5%
0603
R3509 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R3510 0613952J25 CER CHIP RES 100K OHM 5%
0603
R3511 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R3513 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
RT3404 0686462W35 MULTI-LAYER NTC THERMIS-
TOR 10K OHM +/- 1%
Circuit
Ref
Motorola
Part No.
Description
SH3301 2602641Y03 SHIELD, ARIANE VCO
T3001 2566506A01 BALUN TRANSFORMER
T3002 2566506A02 BALUN TRANSFORMER
U3101 5115281H01 FM IF IC SA616 FROM PHILIPS
U3111 5185291Y01 IC,SOIC14
U3115 5185291Y01 IC,SOIC14
U3201 5185177Y01 IC TESTED AT25016 48 PIN
W18
U3211 5115026H01 MAX SUPPLY VOL 16V
U3301 5171121L01 CUSTOM LOW VOLTAGE VCO
BUFFER IC
U3401 51012101001 VHF/UHF/800/900 MHZ LDMOS
DRIVER IC
U3402 5114005A01 IC,OP AMP,2PER
PKG,GP,SM,SO-8,PB-FREE
U3501 5185765B26 IC PWR CTRL IN MOS20
U3502 5115022H01 IC TEMPERATURE SENSOR
VR3471 4813977M11 DIODE,ZEN,MBZ5232,SM,SOT-
23,5.6V,10MA,.225W,ZEN,PB-
FREE
Y3101 4802245J84 XTAL 44.395MHZ, 3RD OT,
SMD
Y3102 9186145B02 CER.DISCR. CDBCA455CX36-
TC
Y3263 4816142H01 REFERENCE OSCILLATOR
Circuit
Ref
Motorola
Part No.
Description
