Motorola Pro3100 Detailed Service Manual

Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists Section 7: 4-45
6881091C63-F
C1607 2113740F51 CAP, 100pF
C1608 2113743A23 CAP, 0.22uF
C1609 2113740F34 CAP, 20pF
C1610 2113741F41 CAP, 4700pF
C1611 2113743E20 CAP, 0.1uF
C1612 2113741F33 CAP, 2200pF
C1613 2113740F54 CAP, 130pF
C1614 2113741F24 CAP, 910pF
C1615 NOT PLACED
C1616 2113740F40 CAP, 36pF
C1618 2113743A23 CAP, 0.22uF
C1619 2311049A57 CAP, 10uF
C1620 2113741F25 CAP, 1000pF
C1621 NOT PLACED
C1622 2113743E20 CAP, 0.1uF
C1623 2113740F60 CAP, 240pF
C1624 2113741F37 CAP, 3300pF
C1625 2113740F29 CAP, 12pF
C1626 2113740F59 CAP, 220pF
C1627 2113743A23 CAP, 0.22uF
C1628 2113743E20 CAP, 0.1uF
C1629 2113740F39 CAP, 33pF
C1631 2311049A57 CAP, 10uF
C1632 2113743E20 CAP, 0.1uF
C1633 2113743A23 CAP, 0.22uF
C1634 2113741A45 CAP, .01uF
CR1201 4802245J22 1T363
CR1202 4802233J09 IMN10
CR1302 4805649Q14 HN1V02H
CR1306 4880154K03 MMBD353
CR1310 4805649Q14 HN1V02H
CR1314 4880154K03 MMBD353
D0101 4880236E05 Schottky
D0151 4813833C02 Dual
D0179 4813833C02 Dual
D0621 4813833C02 Dual
D0651 4813833C02 Dual
D0660 4813833C02 Dual
D0661 4813833C02 Dual
D1001 4880154K03 MMBD353
D1101 4880154K03 MMBD353
D1401 4808379X02 MA4P1450
D1402 4808379X02 MA4P1450
D1501 4880236E05 MMBD301
D1502 4813833C02 MMBD6100
D1503 4813833C02 MMBD6100
D1601 4880154K03 MMBD353
E0271 2484657R01 Ferrite Bead
E0272 2484657R01 Ferrite Bead
E0631 2484657R01 Ferrite Bead
E1401 2408380X02 2773037446
Circuit
Ref
Motorola
Part No.
Description
E1403 2408380X02 2773037446
F0401 06580542Z01 FUSE
FL1101 9180656U03 CFEC10_7MG1
FL1102 9180022M09 FILTER
FL1104 9180468V04 CFUCJ455F
FL1105 9180468V05 CFUCJ455E
FL1106 9180469V04 CFWC455F
FL1107 9180469V05 CFWC455E
J0401 0902636Y02 Connector, Flex, 12-pin
J0451 0902636Y01 Conn, Flex, Side Entry
J0501 0986105B01 Connector, SMD, 20-pin
J0551 0905505Y04 Conn, ZIF
J0552 0905505Y03 Conn, 18-Pin
J0601 0986165B01 DC Power Connector
J1401 0986166B02 CONN_J
L1001 2408382A11 IDCTR, 130nH
L1002 2408382C11 IDCTR, 130nH
L1003 2408382A11 IDCTR, 130nH
L1004 2408382C11 IDCTR, 130nH
L1005 2408382A11 IDCTR, 130nH
L1006 2408382A11 IDCTR, 130nH
L1007 2408382C11 IDCTR, 130nH
L1008 2408382A11 IDCTR, 130nH
L1009 2408382C11 IDCTR, 130nH
L1010 2408382A11 IDCTR, 130nH
L1011 2462587N68 IDCTR, 1uH
L1012 2462587N57 IDCTR, 220nH
L1013 2462587N59 IDCTR, 330nH
L1014 2462587N57 IDCTR, 220nH
L1101 2462587N33 IDCTR, 1.8uH
L1102 2408383X07 IDCTR, 3.3uH
L1103 2462587N33 IDCTR, 1.8uH
L1104 2480289M10 IDCTR, 6.8uH
L1105 2480289M10 IDCTR, 6.8uH
L1106 2462587N33 IDCTR, 1.8uH
L1107 2480289M09 IDCTR, 5.6uH
L1108 NOT PLACED
L1109 NOT PLACED
L1110 2480289M18 IDCTR, 33uH
L1111 2408383X07 IDCTR, 3.3uH
L1112 2483411T35 IDCTR, 6.8uH
L1201 2480289M17 IDCTR, 27uH
L1202 2462587Q20 IDCTR, 2.2uH
L1204 NOT PLACED
L1205 2462587N62 IDCTR, 560nH
L1206 2480289M17 IDCTR, 27uH
L1207 NOT PLACED
L1302 2408382D19 IDCTR, 491nH
L1303 2480289M17 IDCTR, 27uH"
L1304 2462587N66 IDCTR, 820nH
L1305 2480289M17 IDCTR, 27uH
Circuit
Ref
Motorola
Part No.
Description
L1306 2480289M17 IDCTR, 27uH
L1307 2480289M17 IDCTR, 27uH
L1309 2480289M17 IDCTR, 27uH
L1310 2462587N60 IDCTR, 390nH
L1311 2480289M17 IDCTR, 27uH
L1313 2408382D19 IDCTR, 491nH
L1314 2480289M18 IDCTR, 33uH
L1315 2462587N69 IDCTR, 1.2uH
L1316 2480289M18 IDCTR, 33uH
L1317 2480289M18 IDCTR, 33uH
L1318 2480289M18 IDCTR, 33uH
L1321 2462587N58 IDCTR, 270nH
L1322 2480289M18 IDCTR, 33uH
L1324 2480289M18 IDCTR, 33uH
L1401 NOT PLACED
L1402 2462587U09 IDCTR, 4.7uH
L1403 2462587U09 IDCTR, 4.7uH
L1404 2462587N56 IDCTR, 180nH
L1405 NOT PLACED
L1406 2408381X36 IDCTR, 250.974nH
L1413 2408381X17 IDCTR, 88.470nH
L1414 2408381X17 IDCTR, 88.470nH
L1415 2460591X02 IDCTR, 25nH
L1416 2460591X02 IDCTR, 25nH
L1417 2460591X02 IDCTR, 25nH
L1418 2408381X17 IDCTR, 88.470nH
L1419 2480289M17 IDCTR, 27uH
L1420 2408381X31 IDCTR, 196.876nH
L1421 2408381X27 IDCTR, 150.499nH
L1422 2408381X24 IDCTR, 133.304nH
L1423 2408381X15 IDCTR, 78.727nH
L1424 2408384A08 IDCTR, 82nH
L1425 2460591X02 IDCTR, 25nH
L1426 2460591X02 IDCTR, 25nH
L1601 2483411T45 IDCTR, 47uH
L1602 2483411T45 IDCTR, 47uH
L1603 2483411T73 IDCTR, 1uH
L1604 2483411T45 IDCTR, 47uH
L1605 2483411T41 IDCTR, 22uH
L1606 2462587T30 IDCTR, 1uH
L1607 2462587T30 IDCTR, 1uH
M1401 2686201B01 HEATSINK
Q0110 4880048M01 NPN
Q0151 4880048M01 NPN
Q0171 4880048M01 NPN
Q0173 4880052M01 NPN
Q0177 4880048M01 NPN
Q0181 4880048M01 NPN
Q0183 4880048M01 NPN
Q0185 4880048M01 NPN
Q0271 4813824A10 NPN
Circuit
Ref
Motorola
Part No.
Description
Q0641 4880048M01 NPN
Q0661 4805921T02 DUAL
Q0662 4813824A10 NPN
Q0663 4880048M01 NPN
Q0681 4880052M01 NPN
Q1001 4880173R01 MMBR951
Q1002 4813824A17 MMBT3906
Q1003 4813824A17 MMBT3906
Q1101 4813827A07 MMBR941
Q1102 4813823A05 MMBFU310L
Q1103 4813823A05 MMBFU310L
Q1104 4813823A05 MMBFU310L
Q1105 4880048M01 DTC144EKA
Q1106 4813827A07 MMBR941
Q1201 4813824A17 MMBT3906
Q1202 4880173R01 MMBR951
Q1303 4884235R02 MMBFU310
Q1304 4880173R01 MMBR951
Q1305 4880173R01 MMBR951
Q1306 4884235R02 MMBFU310
Q1307 4880173R01 MMBR951
Q1308 4880173R01 MMBR951
Q1401 4886212B01 MRF1518
Q1402 4886136B01 36B01
Q1403 4886136B01 36B01
Q1404 NOT PLACED
Q1501 4880141L03 BCW68G
Q1502 4813824A10 MMBT3904
Q1503 4813824A10 MMBT3904
Q1504 4813824A10 MMBT3904
Q1505 4813824A17 MMBT3906
Q1506 4813824A10 MMBT3904
Q1601 4813824A17 MMBT3906
Q1602 4880048M01 DTC144EKA
Q1603 4813824A10 MMBT3904
Q1604 4813824A10 MMBT3904
Q1605 4813824A10 MMBT3904
Q1606 4813824A17 MMBT3906
Q1607 4813824A10 MMBT3904
Q1609 4813824A17 MMBT3906
Q1610 4805585Q17 NE25139
R0101 0662057A73 10K
R0102 0662057A65 4.7K
R0104 0662057A73 10K
R0105 0662057A97 100K
R0108 0662057A57 2.2K
R0111 0662057B47 0
R0113 0662057A73 10K
R0114 0662057A73 10K
R0115 0662057A73 10K
R0117 0662057A63 3.9K
Circuit
Ref
Motorola
Part No.
Description
