Motorola Pro3100 Detailed Service Manual

Section 7: 4-46 Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists
6881091C63-F
R0121 0662057A97 100K
R0131 0662057B46 10.0M
R0132 0662057B10 330K
R0151 0662057A82 24K
R0152 0662057A82 24K
R0170 0662057A73 10K
R0171 0662057A65 4.7K
R0172 0662057A73 10K
R0173 0662057A65 4.7K
R0174 0662057A73 10K
R0175 0662057A73 10K
R0176 0662057A84 30K
R0177 0662057A65 4.7K
R0178 0662057A89 47K
R0179 0662057A89 47K
R0181 0662057A65 4.7K
R0182 0662057A89 47K
R0183 0662057A65 4.7K
R0184 0662057A89 47K
R0185 0662057A65 4.7K
R0186 0662057A89 47K
R0201 0662057A25 100
R0202 0662057A43 560
R0203 0662057A25 100
R0204 0662057A43 560
R0205 0662057A73 10K
R0206 0662057A73 10K
R0207 0662057A57 2.2K
R0208 0662057A57 2.2K
R0211 0660076E70 7.5K
R0212 0660076E70 7.5K
R0221 0662057A82 24K
R0222 0662057A82 24K
R0223 0662057A84 30K
R0224 0662057A71 8.2K
R0228 0662057B47 0
R0229 0662057A01 10
R0241 0662057A89 47K
R0242 0662057B47 0
R0251 0662057A89 47K
R0252 0662057A91 56K
R0253 0662057A97 100K
R0254 0662057A73 10K
R0255 0662057A73 10K
R0556 0662057A97 100K
R0257 0662057A57 2.2K
R0261 0662057A73 10K
R0262 0662057A97 100K
R0265 0662057A82 24K
R0267 0662057A89 47K
R0268 0662057A73 10K
Circuit
Ref
Motorola
Part No.
Description
R0269 0662057A41 470
R0273 0662057A82 24K
R0275 0662057A73 10K
R0276 0662057A77 15K
R0401 0662057A33 220
R0407 0662057M26 10
R0408 0662057A25 100
R0409 0662057M26 10
R0412 0662057B47 0
R0441 0662057B47 0
R0242 0662057A49 1K
R0467 0662057M26 10
R0468 0662057M26 10
R0481 0662057B47 0
R0482 0662057B47 0
R0510 0662057A65 4.7K
R0511 0662057A97 100K
R0512 0662057A77 15K
R0525 0662057A97 100K
R0529 0662057A89 47K
R0530 0662057B47 0
R0531 0662057A43 560
R0533 0662057B47 0
R0535 0662057A49 1K
R0537 0662057A33 220
R0538 0662057A33 220
R0539 0662057A65 4.7K
R0541 0662057A83 27K
R0543 0662057A97 100K
R0591 0662057A82 24K
R0592 0662057A01 10
R0593 0662057A97 100K
R0611 0662057A91 56K
R0612 0662057A65 4.7K
R0621 0662057A82 24K
R0641 0662057A73 10K
R0642 0660076E70 7.5K
R0643 0660076E51 1.2K
R0651 0662057A01 10
R0652 0662057A01 10
R0661 0662057A49 1K
R0662 0662057B02 150K
R0671 0662057A84 30K
R0672 0662057A73 10K
R0681 0662057A79 18K
R0682 0662057A93 68K
R1001 0662057A05 RES, 15
R1002 0662057A05 RES, 15
R1003 0662057A41 RES, 470
R1004 0662057A59 RES, 2.7K
R1005 0662057A31 RES, 180
Circuit
Ref
Motorola
Part No.
Description
R1006 0662057A73 RES, 10K
R1007 0662057A71 RES, 8.2K
R1008 0662057A65 RES, 4.7K
R1009 NOT PLACED
R1010 NOT PLACED
R1011 NOT PLACED
R1101 0662057A18 RES, 51
R1102 0662057A78 RES, 16K
R1103 0662057A39 RES, 390
R1104 0662057A71 RES, 8.2K
R1106 0662057A25 RES, 100
R1107 0662057A68 RES, 6.2K
R1108 0662057A61 RES, 3.3K
R1109 0662057A37 RES, 330
R1110 0662057A25 RES, 100
R1111 0662057A17 RES, 47
R1113 0662057A64 RES, 4.3K
R1114 0662057A64 RES, 4.3K
R1115 0662057A75 RES, 12K
R1116 NOT PLACED
R1117 0662057A37 RES, 330
R1118 0662057A56 RES, 2K
R1119 0662057A83 RES, 27K
R1120 0662057A18 RES, 51
R1121 0662057A71 RES, 8.2K
R1122 0662057A73 RES, 10K
R1123 0662057A51 RES, 1.2K
R1124 NOT PLACED
R1125 NOT PLACED
R1126 NOT PLACED
R1127 NOT PLACED
R1128 0662057A73 RES, 10K
R1129 0662057A73 RES, 10K
R1130 0662057A73 RES, 10K
R1131 0662057A77 RES, 15K
R1132 0662057A58 RES, 2.4K
R1133 0662057A61 RES, 3.3K
R1134 0662057A05 RES, 15
R1135 0662057A20 RES, 62
R1136 0662057A45 RES, 680
R1137 0662057A75 RES, 12K
R1138 0662057A01 RES, 10
R1139 0611077A12 RES, 2.7
R1201 0662057B47 RES, 0
R1202 NOT PLACED
R1203 0662057B02 RES, 150K
R1204 0662057B47 RES, 0
R1205 0662057A45 RES, 680
R1206 0662057A41 RES, 470
R1207 NOT PLACED
R1208 0662057A18 RES, 51
Circuit
Ref
Motorola
Part No.
Description
R1209 0662057A61 RES, 3.3K
R1210 0662057A33 RES, 220
R1211 0662057B14 RES, 470K
R1212 0662057A25 RES, 100
R1213 0662057A45 RES, 680
R1214 0662057A54 RES, 1.6K
R1215 0662057A21 RES, 68
R1216 0662057A18 RES, 51
R1217 0662057A25 RES, 100
R1218 0662057A17 RES, 47
R1219 0662057A17 RES, 47
R1220 0662057A17 RES, 47
R1221 0662057B47 RES, 0
R1222 NOT PLACED
R1306 0662057B47 RES, 0
R1307 0662057A19 RES, 56
R1308 0662057A19 RES, 56
R1309 0662057A41 RES, 470
R1311 0662057A73 RES, 10K
R1312 0662057A51 RES, 1.2K
R1313 0662057A51 RES, 1.2K
R1314 0662057A37 RES, 330
R1315 0662057A61 RES, 3.3K
R1316 0662057A45 RES, 680
R1317 0662057A09 RES, 22
R1318 0662057A41 RES, 470
R1319 0662057A01 RES, 10
R1320 0662057A41 RES, 470
R1325 0662057B47 RES, 0
R1326 0662057A19 RES, 56
R1327 0662057A19 RES, 56
R1328 0662057A41 RES, 470
R1330 0662057A73 RES, 10K
R1331 0662057A51 RES, 1.2K
R1332 0662057A51 RES, 1.2K
R1333 0662057A37 RES, 330
R1334 0662057A61 RES, 3.3K
R1335 0662057A47 RES, 820
R1336 0662057A09 RES, 22
R1337 0662057A22 RES, 75
R1338 0662057A27 RES, 120
R1339 0662057A22 RES, 75
R1340 0662057A49 RES, 1K
R1341 0662057A25 RES, 100
R1342 0662057A25 RES, 100
R1343 0662057C55 RES, 150
R1344 0662057A49 RES, 1K
R1345 0662057A25 RES, 100
R1346 0662057A25 RES, 100
R1347 0662057C55 RES, 150
R1376 0662057A65 RES, 4.7K
Circuit
Ref
Motorola
Part No.
Description
