Motorola Pro3100 Detailed Service Manual

Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists Section 7: 4-49
6881091C63-F
C1034 2113740F51 CAP, 100pF
C1035 2113740F46 CAP, 62pF
C1036 2113743E20 CAP, 0.1uF
C1037 2113740F59 CAP, 220pF
C1038 2113740F62 CAP, 300pF
C1039 2113740F62 CAP, 300pF
C1040 2113740F59 CAP, 220pF
C1101 2113740F53 CAP, 120pF
C1102 2113740F50 CAP, 91pF
C1103 2113740F58 CAP, 200pF
C1104 2113743E20 CAP, 0.1uF
C1105 2113743E20 CAP, 0.1uF
C1106 2113743E20 CAP, 0.1uF
C1107 2113740F49 CAP, 82pF
C1108 2113743E20 CAP, 0.1uF
C1109 2113740F40 CAP, 36pF
C1110 Not Placed
C1111 2113740L03 CAP, 2.4pF
C1112 2113740F40 CAP, 36pF
C1113 2113743E20 CAP, 0.1uF
C1114 2113743E20 CAP, 0.1uF
C1115 2113740F53 CAP, 120pF
C1116 2113740F41 CAP, 39pF
C1119 2113743E20 CAP, 0.1uF
C1120 Not Placed
C1121 Not Placed
C1122 Not Placed
C1123 2113740F39 CAP, 33pF
C1124 2113743E20 CAP, 0.1uF
C1125 2113743E11 CAP, .039uF
C1126 2113743E20 CAP, 0.1uF
C1127 2311049A57 CAPP, 10uF
C1128 2113743E20 CAP, 0.1uF
C1129 2113740F35 CAP, 22pF
C1130 2113740F47 CAP, 68pF
C1131 Not Placed
C1133 2113743E20 CAP, 0.1uF
C1134 2113743E20 CAP, 0.1uF
C1135 2113743E20 CAP, 0.1uF
C1136 2113743E20 CAP, 0.1uF
C1137 2113740F53 CAP, 120pF
C1138 2113743E20 CAP, 0.1uF
C1139 2113741F49 CAP, .01uF
C1140 2113741F49 CAP, .01uF
C1141 2113743E20 CAP, 0.1uF
C1142 2113743E20 CAP, 0.1uF
C1143 2113743E20 CAP, 0.1uF
C1144 2113743E20 CAP, 0.1uF
C1145 2113741F41 CAP, 4700pF
C1146 2113740F49 CAP, 82pF
C1147 2113740F65 CAP, 390pF
Circuit
Ref
Motorola
Part No.
Description
C1148 2113743E20 CAP, 0.1uF
C1149 2113740F53 CAP, 120pF
C1150 2113740F54 CAP, 130pF
C1151 Not Placed
C1152 Not Placed
C1153 Not Placed
C1201 2113743E20 CAP, 0.1uF
C1202 2311049J11 CAPP, 4.7uF
C1203 2113741F49 CAP, .01uF
C1204 2113740F59 CAP, 220pF
C1205 Not Placed
C1206 2113740L37 CAP, 62pF
C1207 2113740F07 CAP, 1.5pF
C1208 2113740A82 CAP, 1500pF
C1209 2311049A57 CAPP, 10uF
C1210 2113743E20 CAP, 0.1uF
C1211 2113741F49 CAP, .01uF
C1212 2311049A07 CAPP, 1uF
C1213 2113743A23 CAP, 0.22uF
C1214 2113743E10 CAP, .033uF
C1215 2113740C37 CAP, 6800pF
C1216 2311049J11 CAPP, 4.7uF
C1217 2113741F49 CAP, .01uF
C1218 2113743E20 CAP, 0.1uF
C1219 2311049J11 CAPP, 4.7uF
C1220 2311049J11 CAPP, 4.7uF
C1221 Not Placed
C1222 2113740F36 CAP, 24pF
C1223 2113741F49 CAP, .01uF
C1224 2113740F49 CAP, 82pF
C1225 2113741F49 CAP, .01uF
C1226 Not Placed
C1227 2113741F49 CAP, .01uF
C1228 Not Placed
C1229 2113741F49 CAP, .01uF
C1230 2113741F49 CAP, .01uF
C1231 2113741F49 CAP, .01uF
C1232 Not Placed
C1233 Not Placed
C1234 Not Placed
C1250 2311049A09 CAPP, 2.2uF
C1251 2113743E20 CAP, 0.1uF
C1252 2113743E05 CAP, .018uF
C1253 2311049J11 CAPP, 4.7uF
C1254 2113741F49 CAP, .01uF
C1304 Not Placed
C1305 Not Placed
C1306 2113740L23 CAP, 16pF
C1307 2113740L27 CAP, 24pF
C1308 2113740F19 CAP, 4.7pF
C1309 Not Placed
Circuit
Ref
Motorola
Part No.
Description
C1311 2113741F49 CAP, .01uF
C1312 2113741F49 CAP, .01uF
C1313 2113741F49 CAP, .01uF
C1314 2113740L27 CAP, 24pF
C1315 2113740L27 CAP, 24pF
C1316 2113740F15 CAP, 3.3pF
C1317 2113743E20 CAP, 0.1uF
C1318 2113741F49 CAP, .01uF
C1319 2113741F49 CAP, .01uF
C1320 2113741F49 CAP, .01uF
C1321 2113740F17 CAP, 3.9pF
C1323 2113740L21 CAP, 13pF
C1325 2113741F49 CAP, .01uF
C1326 2113741F49 CAP, .01uF
C1333 2113740L28 CAP, 27pF
C1334 2113740L36 CAP, 56pF
C1335 2113740F19 CAP, 4.7pF
C1336 2113743E20 CAP, 0.1uF
C1337 Not Placed
C1338 2113741F49 CAP, .01uF
C1339 2113741F49 CAP, .01uF
C1340 2113741F49 CAP, .01uF
C1341 2113740L36 CAP, 56pF
C1342 2113740L36 CAP, 56pF
C1343 2113740F15 CAP, 3.3pF
C1344 2113741F49 CAP, .01uF
C1345 2113743E20 CAP, 0.1uF
C1346 2113741F49 CAP, .01uF
C1347 2113741F49 CAP, .01uF
C1348 2113740F17 CAP, 3.9pF
C1349 2113743E20 CAP, 0.1uF
C1350 2113740F31 CAP, 15pF
C1351 2113741F49 CAP, .01uF
C1352 2113741F49 CAP, .01uF
C1354 Not Placed
C1356 Not Placed
C1360 Not Placed
C1361 Not Placed
C1362 Not Placed
C1401 2113741A45 CAP, .01uF
C1402 2113741A45 CAP, .01uF
C1403 Not Placed
C1404 2113741A45 CAP, .01uF
C1405 2113741A45 CAP, .01uF
C1406 Not Placed
C1407 2113741A45 CAP, .01uF
C1408 Not Placed
C1409 Not Placed
C1410 2113741M69 CAP, 0.1uF
C1412 2113741A45 CAP, .01uF
C1413 2113741A45 CAP, .01uF
Circuit
Ref
Motorola
Part No.
Description
C1414 2113741A45 CAP, .01uF
C1415 2113741M69 CAP, 0.1uF
C1416 Not Placed
C1417 Not Placed
C1418 2113740A73 CAP, 560pF
C1419 2113741A45 CAP, .01uF
C1420 2113741A45 CAP, .01uF
C1421 Not Placed
C1422 Not Placed
C1423 2113741A45 CAP, .01uF
C1424 2113741A45 CAP, .01uF
C1425 2113741W01 CAP, 1uF
C1426 2113741W01 CAP, 1uF
C1427 2111078B59 CAP, 470pF
C1428 2111078B59 CAP, 470pF
C1429 2111078B58 CAP, 430pF
C1430 2111078B58 CAP, 430pF
C1431 2113741A45 CAP, .01uF
C1432 2113741W01 CAP, 1uF
C1433 2113741W01 CAP, 1uF
C1434 2113741A45 CAP, .01uF
C1435 2113741W01 CAP, 1uF
C1436 2113741A45 CAP, .01uF
C1437 2111078B58 CAP, 430pF
C1438 2111078B58 CAP, 430pF
C1439 2111078B59 CAP, 470pF
C1440 2111078B59 CAP, 470pF
C1441 2111078B52 CAP, 240pF
C1442 2111078B45 CAP, 130pF
C1443 2111078B59 CAP, 470pF
C1444 2111078B59 CAP, 470pF
C1445 2113741A45 CAP, .01uF
C1446 Not Placed
C1447 2111078B52 CAP, 240pF
C1448 2111078B52 CAP, 240pF
C1449 2180060M49 CAP, 180pF
C1450 Not Placed
C1451 2180060M49 CAP, 180pF
C1452 2180060M29 CAP, 27pF
C1453 2180060M42 CAP, 91pF
C1454 2180060M38 CAP, 62pF
C1455 2180060M30 CAP, 30pF
C1456 2180060M40 CAP, 75pF
C1457 2113741A45 CAP, .01uF
C1458 2311049C01 CAPP, 10uF
C1459 2311049C01 CAPP, 10uF
C1460 2113743E20 CAP, 0.1uF
C1461 2113741A45 CAP, .01uF
C1462 2311049C01 CAPP, 10uF
C1463 2113928E01 CAP, 1uF
C1464 2113741A45 CAP, .01uF
Circuit
Ref
Motorola
Part No.
Description
