Motorola Pro3100 Detailed Service Manual

Section 7: 4-50 Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists
6881091C63-F
C1465 2113928E01 CAP, 1uF
C1466 2113741A45 CAP, .01uF
C1467 2113740A46 CAP, 47pF
C1468 2113741A45 CAP, .01uF
C1469 2113741W01 CAP, 1uF
C1470 2113741W01 CAP, 1uF
C1471 2113741A45 CAP, .01uF
C1472 2113741M69 CAP, 0.1uF
C1473 2113741M69 CAP, 0.1uF
C1474 2113741A45 CAP, .01uF
C1475 2113741W01 CAP, 1uF
C1476 2113741A45 CAP, .01uF
C1477 2111078B42 CAP, 100pF
C1478 2111078B42 CAP, 100pF
C1479 2111078B52 CAP, 240pF
C1480 2111078B54 CAP, 300pF
C1481 2111078B54 CAP, 300pF
C1482 2113928E01 CAP, 1uF
C1484 2113741F33 CAP, 2200pF
C1485 2113741A45 CAP, .01uF
C1501 2113741F33 CAP, 2200pF
C1502 2113741F33 CAP, 2200pF
C1503 2113741F33 CAP, 2200pF
C1504 2113741F33 CAP, 2200pF
C1505 2113741F25 CAP, 1000pF
C1506 2113741F25 CAP, 1000pF
C1507 2113741F33 CAP, 2200pF
C1508 2113741F33 CAP, 2200pF
C1509 2311049A07 CAPP, 1uF
C1510 2113741F33 CAP, 2200pF
C1511 2113741F33 CAP, 2200pF
C1512 2113741F33 CAP, 2200pF
C1525 2113743E20 CAP, 0.1uF
C1526 2113740F51 CAP, 100pF
C1527 2113741A45 CAP, .01uF
C1528 2113741A45 CAP, .01uF
C1529 2113741M69 CAP, 0.1uF
C1530 2113741A45 CAP, .01uF
C1531 Not Placed
C1532 Not Placed
C1601 2113743E20 CAP, 0.1uF
C1602 2113740F59 CAP, 220pF
C1603 2113743A23 CAP, 0.22uF
C1604 2113743A23 CAP, 0.22uF
C1605 2311049A57 CAPP, 10uF
C1606 2113740F59 CAP, 220pF
C1607 2113740F51 CAP, 100pF
C1608 2113743A23 CAP, 0.22uF
C1609 2113740F34 CAP, 20pF
C1610 2113741F41 CAP, 4700pF
C1611 2113743E20 CAP, 0.1uF
Circuit
Ref
Motorola
Part No.
Description
C1612 2113741F33 CAP, 2200pF
C1613 2113740F54 CAP, 130pF
C1614 2113741F24 CAP, 910pF
C1615 Not Placed
C1616 2113740F40 CAP, 36pF
C1618 2113743A23 CAP, 0.22uF
C1619 2311049A57 CAPP, 10uF
C1620 2113741F25 CAP, 1000pF
C1621 Not Placed
C1622 2113743E20 CAP, 0.1uF
C1623 2113740F60 CAP, 240pF
C1624 2113741F37 CAP, 3300pF
C1625 2113740F29 CAP, 12pF
C1626 2113740F59 CAP, 220pF
C1627 2113743A23 CAP, 0.22uF
C1628 2113743E20 CAP, 0.1uF
C1629 2113740F39 CAP, 33pF
C1631 2311049A57 CAPP, 10uF
C1632 2113743E20 CAP, 0.1uF
C1633 2113743A23 CAP, 0.22uF
C1634 2113741A45 CAP, .01uF
CR1201 4862824C03 1SV232
CR1202 4802233J09 IMN10
CR1302 4805649Q14 HN1V02H
CR1306 4880154K03 MMBD353
CR1310 4805649Q14 HN1V02H
CR1314 4880154K03 MMBD353
D0101 4813825A05 MMBD301
D0151 4813833C02 MMBD6100
D0179 4813833C02 MMBD6100
D0201 Not Placed
D0301 Not Placed
D0621 4813833C02 MMBD6100
D0651 4813833C02 MMBD6100
D0660 4813833C02 MMBD6100
D0661 4813833C02 MMBD6100
D1001 4880154K03 MMBD353
D1101 4880154K03 MMBD353
D1401 4808379X02 MA4P1450
D1402 4808379X02 MA4P1450
D1501 4813825A05 MMBD301
D1502 4813833C02 MMBD6100
D1503 4813833C02 MMBD6100
D1601 4880154K03 MMBD353
E0271 2484657R01 FERRITE BEAD
E0272 2484657R01 FERRITE BEAD
E0631 2484657R01 FERRITE BEAD
E1401 2408380X02 FERRITE BEAD
E1403 2408380X02 FERRITE BEAD
F0401 6580542Z01 FUSE
FL1101 9180656U03 CFEC10_7MG1
Circuit
Ref
Motorola
Part No.
Description
FL1102 9180022M09 CRYSTAL FILTER, 10.7 MHZ
FL1104 9180468V04 CFUCJ455F
FL1105 9180468V05 CFUCJ455E
FL1106 9180469V04 CFWC455F
FL1107 9180469V05 CFWC455E
J0401 0902636Y02 CONN, 12-PIN, CONTROL
HEAD
J0451 0902636Y01 CONN, 18-PIN, EXPANSION
BOARD
J0501 0986105B01 CONN, 20-PIN, ACCESSORY
J0551 0905505Y04 CONN, 40-PIN, INTERNAL
OPTION
J0552 0905505Y03 CONN, 18-PIN, RS232
J0601 0986165B01 DC POWER CONNECTOR
J1401 0986166B02 MINI-U ANTENNA
CONNECTOR
L0481 Not Placed
L0482 Not Placed
L1001 2408382A11 IDCTR, 130nH
L1002 2408382C11 IDCTR, 130nH
L1003 2408382A11 IDCTR, 130nH
L1004 2408382C11 IDCTR, 130nH
L1005 2408382A11 IDCTR, 130nH
L1006 2408382A11 IDCTR, 130nH
L1007 2408382C11 IDCTR, 130nH
L1008 2408382A11 IDCTR, 130nH
L1009 2408382C11 IDCTR, 130nH
L1010 2408382A11 IDCTR, 130nH
L1011 2462587N68 IDCTR, 1uH
L1012 2462587N57 IDCTR, 220nH
L1013 2462587N59 IDCTR, 330nH
L1014 2462587N57 IDCTR, 220nH
L1101 2462587N33 IDCTR, 1.8uH
L1102 2408383X07 IDCTR, 3.3uH
L1103 2462587N33 IDCTR, 1.8uH
L1104 2480289M10 IDCTR, 6.8uH
L1105 2480289M10 IDCTR, 6.8uH
L1106 2462587N33 IDCTR, 1.8uH
L1107 2480289M09 IDCTR, 5.6uH
L1108 Not Placed
L1109 Not Placed
L1110 2480289M18 IDCTR, 33uH
L1111 2408383X07 IDCTR, 3.3uH
L1112 2483411T35 IDCTR, 6.8uH
L1201 2480289M17 IDCTR, 27uH
L1202 2462587Q20 IDCTR, 2.2uH
L1204 Not Placed
L1205 2462587N62 IDCTR, 560nH
L1206 2480289M17 IDCTR, 27uH
L1207 Not Placed
L1302 2408382D19 IDCTR, 491nH
Circuit
Ref
Motorola
Part No.
Description
L1303 2480289M17 IDCTR, 27uH
L1304 2462587N66 IDCTR, 820nH
L1305 2480289M17 IDCTR, 27uH
L1306 2480289M17 IDCTR, 27uH
L1307 2480289M17 IDCTR, 27uH
L1309 2480289M17 IDCTR, 27uH
L1310 2462587N60 IDCTR, 390nH
L1311 2480289M17 IDCTR, 27uH
L1313 2408382D19 IDCTR, 491nH
L1314 2480289M18 IDCTR, 33uH
L1315 2462587N69 IDCTR, 1.2uH
L1316 2480289M18 IDCTR, 33uH
L1317 2480289M18 IDCTR, 33uH
L1318 2480289M18 IDCTR, 33uH
L1321 2462587N58 IDCTR, 270nH
L1322 2480289M18 IDCTR, 33uH
L1324 2480289M18 IDCTR, 33uH
L1401 Not Placed
L1402 2462587U09 IDCTR, 4.7uH
L1403 2462587U09 IDCTR, 4.7uH
L1404 2462587N56 IDCTR, 180nH
L1405 Not Placed
L1406 2408381X36 IDCTR, 250.974nH
L1413 2408381X17 IDCTR, 88.470nH
L1414 2408381X17 IDCTR, 88.470nH
L1415 2485873L02 IDCTR, 25nH
L1416 2485873L02 IDCTR, 25nH
L1417 2485873L02 IDCTR, 25nH
L1418 2408381X17 IDCTR, 88.470nH
L1419 2480289M17 IDCTR, 27uH
L1420 2408381X31 IDCTR, 196.876nH
L1421 2408381X27 IDCTR, 150.499nH
L1422 2408381X24 IDCTR, 133.304nH
L1423 2408381X15 IDCTR, 78.727nH
L1424 2408384A08 IDCTR, 82nH
L1425 2485873L02 IDCTR, 25nH
L1426 2485873L02 IDCTR, 25nH
L1601 2483411T45 IDCTR, 47uH
L1602 2483411T45 IDCTR, 47uH
L1603 2483411T73 IDCTR, 1uH
L1604 2483411T45 IDCTR, 47uH
L1605 2483411T41 IDCTR, 22uH
L1606 2462587T30 IDCTR, 1uH
L1607 2462587T30 IDCTR, 1uH
M1401 2686201B01 HEATSINK
Q0110 4880048M01 DTC144EKA
Q0151 4880048M01 DTC144EKA
Q0171 4880048M01 DTC144EKA
Q0173 4880052M01 RXT-A28
Q0177 4880048M01 DTC144EKA
Q0181 4880048M01 DTC144EKA
Circuit
Ref
Motorola
Part No.
Description
