Motorola Pro3100 Detailed Service Manual

Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists Section 7: 4-55
6881091C63-F
C1010 2113740F46 CAP CHIP REEL CL1 +/-30
62
C1011 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1012 2113740F62 CAP CHIP CL1 +/-30 300 5%
C1013 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1014 2113740F56 CAP CHIP REEL CL1 +/-30
160
C1015 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1016 2113740F55 CAP CHIP REEL CL1 +/-30
150
C1017 2113741F27 CAP CHIP CL2 X7R REEL
1200
C1019 2113740F60 CAP CHIP REEL CL1 +/-130
240
C1020 2113740F59 CAP CHIP REEL CL1 +/-30
220
C1021 2113740F62 CAP CHIP CL1 +/-30 300 5%
C1022 2113740F59 CAP CHIP REEL CL1 +/-30
220
C1023 2113740F62 CAP CHIP CL1 +/-30 300 5%
C1024 2113740F59 CAP CHIP REEL CL1 +/-30
220
C1025 2113740F60 CAP CHIP REEL CL1 +/-130
240
C1026 2113741F27 CAP CHIP CL2 X7R REEL
1200
C1027 2113740F55 CAP CHIP REEL CL1 +/-30
150
C1028 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1029 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1030 2113743E26 CAP CHIP .10 UF 10%
C1031 2113743E26 CAP CHIP .10 UF 10%
C1032 2113740F48 CAP CHIP REEL CL1 +/-30
75
C1033 2113740F50 CAP CHIP REEL CL1 +/-30
91
C1034 2113740F51 CAP CHIP REEL CL1 +/-30
100
C1035 2113740F46 CAP CHIP REEL CL1 +/-30
62
C1036 2113743E26 CAP CHIP .10 UF 10%
C1037 2113740F59 CAP CHIP REEL CL1 +/-30
220
C1038 2113740F62 CAP CHIP CL1 +/-30 300 5%
C1039 2113740F62 CAP CHIP CL1 +/-30 300 5%
Circuit
Ref
Motorola
Part No.
Description
C1040 2113740F59 CAP CHIP REEL CL1 +/-30
220
C1101 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1102 2113740F50 CAP CHIP REEL CL1 +/-30
91
C1103 2113740F58 CAP CHIP REEL CL1 +/-30
200
C1104 2113743E26 CAP CHIP .10 UF 10%
C1105 2113743E26 CAP CHIP .10 UF 10%
C1106 2113743E26 CAP CHIP .10 UF 10%
C1107 2113740F49 CAP CHIP REEL CL1 +/-30
82
C1108 2113743E26 CAP CHIP .10 UF 10%
C1109 2113740F40 CAP CHIP REEL CL1 +/-30
36
C1110 NOT PLACED –
C1111 2113740L03 CAP CER CHIP 2.4 PF +-
0.1PF
C1112 2113740F40 CAP CHIP REEL CL1 +/-30
36
C1113 2113743E26 CAP CHIP .10 UF 10%
C1114 2113743E26 CAP CHIP .10 UF 10%
C1115 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1116 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1119 2113743E26 CAP CHIP .10 UF 10%
C1120 NOT PLACED –
C1121 NOT PLACED –
C1122 NOT PLACED –
C1123 2113740F39 CAP CHIP REEL CL1 +/-30
33
C1124 2113743E26 CAP CHIP .10 UF 10%
C1125 2113743E17 CAP CHIP .039 UF 10% X7R
C1126 2113743E26 CAP CHIP .10 UF 10%
C1127 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C1128 2113743E26 CAP CHIP .10 UF 10%
C1129 2113740F35 CAP CHIP REEL CL1 +/-30
22
C1130 2113740F47 CAP CHIP REEL CL1 +/-30
68
C1131 NOT PLACED –
C1133 2113743E26 CAP CHIP .10 UF 10%
C1134 2113743E26 CAP CHIP .10 UF 10%
C1135 2113743E26 CAP CHIP .10 UF 10%
C1136 2113743E26 CAP CHIP .10 UF 10%
C1137 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1138 2113743E26 CAP CHIP .10 UF 10%
Circuit
Ref
Motorola
Part No.
Description
C1139 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1140 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1141 2113743E26 CAP CHIP .10 UF 10%
C1142 2113743E26 CAP CHIP .10 UF 10%
C1143 2113743E26 CAP CHIP .10 UF 10%
C1144 2113743E26 CAP CHIP .10 UF 10%
C1145 2113741F41 CAP CHIP CL2 X7R REEL
4700
C1146 2113740F49 CAP CHIP REEL CL1 +/-30
82
C1147 2113740F65 CAP CHIP CL1 +/-30 390 5%
C1148 2113743E26 CAP CHIP .10 UF 10%
C1149 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1150 2113740F54 CAP CHIP REEL CL1 +/-30
130
C1151 NOT PLACED –
C1152 NOT PLACED –
C1153 NOT PLACED –
C1201 2113743E26 CAP CHIP .10 UF 10%
C1202 2311049J11 CAP TANT CHIP 4.7 10 16
C1203 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1204 2113740F59 CAP CHIP REEL CL1 +/-30
220
C1206 2113740F45 CAP CHIP REEL CL1 +/-30
56
C1207 2113740F07 CAP CHIP REEL CL1 +/-30
1.5
C1208 2113740A82 CAP CHIP REEL CL1 +/-30
1500
C1209 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C1210 2113743E26 CAP CHIP .10 UF 10%
C1211 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1212 2311049A07 CAP TANT CHIP 1 10 16 A/P
C1213 2113743A23 CAP CHIP .220 UF 10% X7R
C1214 2113743E16 CAP CHIP .033 UF 10% X7R
C1215 2113740C37 CAP CHIP REEL CL1 6800
PF 5%
C1216 2311049J11 CAP TANT CHIP 4.7 10 16
C1217 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1218 2113743E26 CAP CHIP .10 UF 10%
C1219 2311049J11 CAP TANT CHIP 4.7 10 16
C1220 2311049J11 CAP TANT CHIP 4.7 10 16
C1222 2113740F36 CAP CHIP REEL CL1 +/-30
24
Circuit
Ref
Motorola
Part No.
Description
C1223 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1224 2113740F49 CAP CHIP REEL CL1 +/-30
82
C1225 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1227 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1229 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1230 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1231 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1250 2311049A09 CAP TANT CHIP 2.2 10 20 A/
P
C1251 2113743E26 CAP CHIP .10 UF 10%
C1252 2113743E11 CER CHIP CAP .018UF
C1253 2311049J11 CAP TANT CHIP 4.7 10 16
C1254 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1306 2113740L23 CAP 16.0 PF 50V 2.0 %
C1307 2113740L27 CAP 24.0 PF 50V 2.0 %
C1308 2113740F19 CAP CHIP REEL CL1 +/-30 4
.7PF
C1311 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1312 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1313 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1314 2113740L27 CAP 24.0 PF 50V 2.0 %
C1315 2113740L27 CAP 24.0 PF 50V 2.0 %
C1316 2113740F15 CAP CHIP REEL CL1 +/-30
3.3
C1317 2113743E26 CAP CHIP .10 UF 10%
C1318 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1319 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1320 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1321 2113740F17 CAP CHIP REEL CL1 +/-30
3.9
C1323 2113740L21 CAP 13.0 PF 50V 2.0 %
C1325 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1326 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1333 2113740L28 CAP 27.0 PF 50V 2.0 %
C1334 2113740L36 CAP 56.0 PF 50V 2.0%
Circuit
Ref
Motorola
Part No.
Description
