Section 7: 4-56 Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists

6881091C63-F

C1335 2113740F19 CAP CHIP REEL CL1 +/-30 4

.7PF

C1336 2113743E26 CAP CHIP .10 UF 10%

C1338 2113741F49 CAP CHIP CL2 X7R REEL

10000

C1339 2113741F49 CAP CHIP CL2 X7R REEL

10000

C1340 2113741F49 CAP CHIP CL2 X7R REEL

10000

C1341 2113740L36 CAP 56.0 PF 50V 2.0%

C1342 2113740L36 CAP 56.0 PF 50V 2.0%

C1343 2113740F15 CAP CHIP REEL CL1 +/-30

3.3

C1344 2113741F49 CAP CHIP CL2 X7R REEL

10000

C1345 2113743E26 CAP CHIP .10 UF 10%

C1346 2113741F49 CAP CHIP CL2 X7R REEL

10000

C1347 2113741F49 CAP CHIP CL2 X7R REEL

10000

C1348 2113740F17 CAP CHIP REEL CL1 +/-30

3.9

C1349 2113743E26 CAP CHIP .10 UF 10%

C1350 2113740F31 CAP CHIP REEL CL1 +/-30

C1351 2113741F49 CAP CHIP CL2 X7R REEL

10000

C1352 2113741F49 CAP CHIP CL2 X7R REEL

10000

C1401 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1402 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1404 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1405 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1407 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1410 2113741M69 CAP CHIP CLS2 100000PF

50V 10%

C1412 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1413 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1414 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1415 2113741M69 CAP CHIP CLS2 100000PF

50V 10%

C1418 2113740A73 CAP CHIP REEL CL1 +/-30

560

Circuit

Ref

Motorola

Part No.

Description

C1419 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1420 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1423 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1424 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1425 2113741W01 P CER 1MF 25V 10%

C1426 2113741W01 P CER 1MF 25V 10%

C1427 2111078B59 CAP CHIP RF 470 5 NPO

100V

C1428 2111078B59 CAP CHIP RF 470 5 NPO

100V

C1429 2111078B58 CAP CHIP RF 430 5 NPO

100V

C1430 2111078B58 CAP CHIP RF 430 5 NPO

100V

C1431 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1432 2113741W01 P CER 1MF 25V 10%

C1433 2113741W01 P CER 1MF 25V 10%

C1434 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1435 2113741W01 P CER 1MF 25V 10%

C1436 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1437 2111078B58 CAP CHIP RF 430 5 NPO

100V

C1438 2111078B58 CAP CHIP RF 430 5 NPO

100V

C1439 2111078B59 CAP CHIP RF 470 5 NPO

100V

C1440 2111078B59 CAP CHIP RF 470 5 NPO

100V

C1441 2111078B52 CAP CHIP RF 240 5 NPO

100V

C1442 2111078B45 CAP CHIP RF 130 5 NPO

100V

C1443 2111078B59 CAP CHIP RF 470 5 NPO

100V

C1444 2111078B59 CAP CHIP RF 470 5 NPO

100V

C1445 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1447 2111078B52 CAP CHIP RF 240 5 NPO

100V

C1448 2111078B52 CAP CHIP RF 240 5 NPO

100V

C1449 2180060M49 CAP MICA CHIP 180.0 5

100V

Circuit

Ref

Motorola

Part No.

Description

C1451 2180060M49 CAP MICA CHIP 180.0 5

100V

C1452 2180060M29 CAP MICA CHIP 27.0 5 500V

C1453 2180060M42 CAP MICA CHIP 91.0 5 500V

C1454 2180060M38 CAP MICA CHIP 62.0 5 500V

C1455 2180060M30 CAP MICA CHIP 30.0 5 500V

C1456 2180060M40 CAP MICA CHIP 75.0 5 500V

C1457 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1458 2311049C01 CAP TANT CHIP 10 UF 35V

10%

C1459 2311049C01 CAP TANT CHIP 10 UF 35V

10%

C1460 2113743E26 CAP CHIP .10 UF 10%

C1461 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1462 2311049C01 CAP TANT CHIP 10 UF 35V

10%

C1463 2113928E01 CAP CER CHIP 1.0 UF 10 %

10V

C1464 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1465 2113928E01 CAP CER CHIP 1.0 UF 10 %

10V

C1466 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1467 2113740A46 CAP CHIP REEL CL1 +/-30

C1468 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1469 2113741W01 P CER 1MF 25V 10%

C1470 2113741W01 P CER 1MF 25V 10%

C1471 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1472 2113741M69 CAP CHIP CLS2 100000PF

50V 10%

C1473 2113741M69 CAP CHIP CLS2 100000PF

50V 10%

C1474 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1475 2113741W01 P CER 1MF 25V 10%

C1476 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1477 2111078B42 CAP CHIP RF 100 5 NPO

100V

C1478 2111078B42 CAP CHIP RF 100 5 NPO

100V

C1479 2111078B52 CAP CHIP RF 240 5 NPO

100V

C1480 2111078B54 CAP CHIP RF 300 5 NPO

100V

Circuit

Ref

Motorola

Part No.

Description

C1481 2111078B54 CAP CHIP RF 300 5 NPO

100V

C1482 2113928E01 CAP CER CHIP 1.0 UF 10 %

10V

C1484 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1485 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1501 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1502 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1503 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1504 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1505 2113741F25 CAP CHIP CL2 X7R REEL

1000

C1506 2113741F25 CAP CHIP CL2 X7R REEL

1000

C1507 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1508 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1509 2311049A07 CAP TANT CHIP 1 10 16 A/P

C1510 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1511 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1512 2113741F33 CAP CHIP CL2 X7R REEL

2200

C1525 2113743E26 CAP CHIP .10 UF 10%

C1526 2113740F51 CAP CHIP REEL CL1 +/-30

100

C1527 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1528 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1529 2113741M69 CAP CHIP CLS2 100000PF

50V 10%

C1530 2113741A45 CHIP CAPACITORS 10000PF

+-5%

C1601 2113743E26 CAP CHIP .10 UF 10%

C1602 2113740F59 CAP CHIP REEL CL1 +/-30

220

C1603 2113743A23 CAP CHIP .220 UF 10% X7R

C1604 2113743A23 CAP CHIP .220 UF 10% X7R

C1605 2311049A57 CAP TANT CHIP A/P 10UF

10% 16V

C1606 2113740F59 CAP CHIP REEL CL1 +/-30

220

Circuit

Ref

Motorola

Part No.

Description
