Control Head CDM1250 / PRO5100 / CDM1550 Series / PRO7100 Troubleshooting Flow Charts Section 2: 3-5

6881091C63-F

2.3 Troubleshooting Flow Chart for Display

Power up alert tone sounds, Volume knob works,

indicator/back light is on, but the display is blank

YES

V5 (against 5V)

TP0973 between

-6V and -7V?

Activity on

Address & Data lines

A0 / D0..D7 / CS1

of U0971?

Check for short

U0831 / U0971

Check LCD Assembly

Check / Replace

C0971 / C0973 / R0972

R0973 / R0974 / U0971
