Section 2: 3-6 Control Head CDM1250 / PRO5100 / CDM1550 Series / PRO7100 Troubleshooting Flow Charts

6881091C63-F

2.4 Troubleshooting Flow Chart for Back Light

Power up alert tone sounds, Volume knob works,

indicator lights up, display works, but back light does not

turn on

YES

U0831 Pin 58

is toggling?

Base of

Q0934

> 0.7V?

Check / Replace

R0847 / C0843 / R0943

Check for short

U0831

YES

Collector of

Q0934

>5V and < 11V?

Check / Replace

Q0934 U0931 /R0941 /

R0942 / R0944 / R0945

Check / Replace

Q0933 / R0947 / R0948
