Motorola Pro3100 Detailed Service Manual

Section 7: 4-94 Low Band Range 3 (42–50 MHz) PCBs, Schematics, and Parts Lists
6881091C63-F
R0642 0660076E75 RES CHIP FILM 7500 1 1/8
R0643 0660076E56 RES CHIP FILM 1200 1 1/8
R0651 0662057A01 CHIP RES 10 OHMS 5%
R0652 0662057A01 CHIP RES 10 OHMS 5%
R0661 0662057A49 CHIP RES 1000 OHMS 5%
R0662 0662057B02 CHIP RES 150K OHMS 5%
R0671 0662057A84 CHIP RES 30K OHMS 5%
R0672 0662057A73 CHIP RES 10K OHMS 5%
R0681 0662057A79 CHIP RES 18K OHMS 5%
R0682 0662057A93 CHIP RES 68K OHMS 5
R1001 0662057A05 CHIP RES 15 OHMS 5%
R1002 0662057A05 CHIP RES 15 OHMS 5%
R1003 0662057A41 CHIP RES 470 OHMS 5%
R1004 0662057A59 CHIP RES 2700 OHMS 5%
R1005 0662057A31 CHIP RES 180 OHMS 5%
R1006 0662057A73 CHIP RES 10K OHMS 5%
R1007 0662057A71 CHIP RES 8200 OHMS 5%
R1008 0662057A65 CHIP RES 4700 OHMS 5%
R1101 0662057A18 CHIP RES 51 OHMS 5%
R1102 0662057A78 CHIP RES 16K OHMS 5%
R1103 0662057A39 CHIP RES 390 OHMS 5%
R1104 0662057A71 CHIP RES 8200 OHMS 5%
R1106 0662057A25 CHIP RES 100 OHMS 5%
R1107 0662057A68 CHIP RES 6200 OHMS 5%
R1108 0662057A61 CHIP RES 3300 OHMS 5%
R1109 0662057A37 CHIP RES 330 OHMS 5%
R1110 0662057A25 CHIP RES 100 OHMS 5%
R1111 0662057A17 CHIP RES 47 OHMS 5%
R1113 0662057A64 CHIP RES 4300 OHMS 5%
R1114 0662057A64 CHIP RES 4300 OHMS 5%
R1115 0662057A75 CHIP RES 12K OHMS 5%
R1116 NOT PLACED –
R1117 0662057A37 CHIP RES 330 OHMS 5%
R1118 0662057A56 CHIP RES 2000 OHMS 5%
R1119 0662057A83 CHIP RES 27K OHMS 5%
R1120 0662057A18 CHIP RES 51 OHMS 5%
R1121 0613952H89 CER CHIP RES 4700 OHM
5% 0603
R1122 0662057A73 CHIP RES 10K OHMS 5%
R1123 0662057A51 CHIP RES 1200 OHMS 5%
R1124 NOT PLACED –
R1125 NOT PLACED –
R1126 NOT PLACED –
R1127 NOT PLACED –
R1128 0662057A73 CHIP RES 10K OHMS 5%
R1129 0662057A73 CHIP RES 10K OHMS 5%
R1130 0662057A73 CHIP RES 10K OHMS 5%
R1131 0662057A77 CHIP RES 15K OHMS 5%
R1132 0662057A58 CHIP RES 2400 OHMS 5%
R1133 0662057A61 CHIP RES 3300 OHMS 5%
R1134 0662057A05 CHIP RES 15 OHMS 5%
Circuit
Ref
Motorola
Part No.
Description
R1135 0662057A20 CHIP RES 62 OHMS 5%
R1136 0662057A45 CHIP RES 680 OHMS 5%
R1137 0662057A75 CHIP RES 12K OHMS 5%
R1138 0662057A01 CHIP RES 10 OHMS 5%
R1139 0611077A12 RES CHIP 2.7 5 1/8W
R1140 0662057A39 CHIP RES 390 OHMS 5%
R1141 0662057A55 CHIP RES 1800 OHMS 5%
R1201 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R1203 0662057B02 CHIP RES 150K OHMS 5%
R1204 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R1205 0662057A45 CHIP RES 680 OHMS 5%
R1206 0662057A41 CHIP RES 470 OHMS 5%
R1208 0662057A18 CHIP RES 51 OHMS 5%
R1209 0662057A61 CHIP RES 3300 OHMS 5%
R1210 0662057A33 CHIP RES 220 OHMS 5%
R1211 0662057B14 CHIP RES 470K OHMS 5%
R1212 0662057A25 CHIP RES 100 OHMS 5%
R1213 0662057A45 CHIP RES 680 OHMS 5%
R1214 0662057A54 CHIP RES 1600 OHMS5%
R1215 0662057A21 CHIP RES 68 OHMS 5%
R1216 0662057A18 CHIP RES 51 OHMS 5%
R1217 0662057A25 CHIP RES 100 OHMS 5%
R1218 0662057A17 CHIP RES 47 OHMS 5%
R1219 0662057A17 CHIP RES 47 OHMS 5%
R1220 0662057A17 CHIP RES 47 OHMS 5%
R1221 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R1306 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R1307 0662057A19 CHIP RES 56 OHMS 5%
R1308 0662057A19 CHIP RES 56 OHMS 5%
R1309 0662057A41 CHIP RES 470 OHMS 5%
R1311 0662057A73 CHIP RES 10K OHMS 5%
R1312 0662057A51 CHIP RES 1200 OHMS 5%
R1313 0662057A51 CHIP RES 1200 OHMS 5%
R1314 0662057A37 CHIP RES 330 OHMS 5%
R1315 0662057A61 CHIP RES 3300 OHMS 5%
R1316 0662057A45 CHIP RES 680 OHMS 5%
R1317 0662057A09 CHIP RES 22 OHMS 5%
R1318 0662057A41 CHIP RES 470 OHMS 5%
R1319 0662057A01 CHIP RES 10 OHMS 5%
R1320 0662057A41 CHIP RES 470 OHMS 5%
R1325 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R1326 0662057A19 CHIP RES 56 OHMS 5%
R1327 0662057A19 CHIP RES 56 OHMS 5%
R1328 0662057A41 CHIP RES 470 OHMS 5%
R1330 0662057A73 CHIP RES 10K OHMS 5%
R1331 0662057A51 CHIP RES 1200 OHMS 5%
Circuit
Ref
Motorola
Part No.
Description
R1332 0662057A51 CHIP RES 1200 OHMS 5%
R1333 0662057A37 CHIP RES 330 OHMS 5%
R1334 0662057A61 CHIP RES 3300 OHMS 5%
R1335 0662057A47 CHIP RES 820 OHMS 5%
R1336 0662057A09 CHIP RES 22 OHMS 5%
R1337 0662057A22 CHIP RES 75 OHMS 5%
R1338 0662057A27 CHIP RES 120 OHMS 5%
R1339 0662057A22 CHIP RES 75 OHMS 5%
R1340 0662057A49 CHIP RES 1000 OHMS 5%
R1341 0662057A25 CHIP RES 100 OHMS 5%
R1342 0662057A25 CHIP RES 100 OHMS 5%
R1343 0662057C55 RES CHIP 150 5% 1/10
R1344 0662057A49 CHIP RES 1000 OHMS 5%
R1345 0662057A25 CHIP RES 100 OHMS 5%
R1346 0662057A25 CHIP RES 100 OHMS 5%
R1347 0662057C55 RES CHIP 150 5% 1/10
R1376 0662057A65 CHIP RES 4700 OHMS 5%
R1402 0611079A64 RES FIXED CHIP 390 5 1/
10W A/P
R1404 0680194M18 RES 51 OHMS 5% 1W
R1405 0680194M18 RES 51 OHMS 5% 1W
R1406 0662057A73 CHIP RES 10K OHMS 5%
R1407 0662057A73 CHIP RES 10K OHMS 5%
R1409 0682089V01 RES CHIP .01 5% 2W
R1410 0683962T52 RES CHIP 130 5-1
R1411 0662057C99 CHIP RES 10 K OHMS 5%
R1413 0680194M01 RES 10 OHMS 5% 1W
R1414 0680194M01 RES 10 OHMS 5% 1W
R1416 0680194M01 RES 10 OHMS 5% 1W
R1417 0680194M01 RES 10 OHMS 5% 1W
R1418 0680194M01 RES 10 OHMS 5% 1W
R1419 0680194M01 RES 10 OHMS 5% 1W
R1420 0680194M01 RES 10 OHMS 5% 1W
R1421 0680194M01 RES 10 OHMS 5% 1W
R1422 0680194M01 RES 10 OHMS 5% 1W
R1423 0680194M01 RES 10 OHMS 5% 1W
R1424 0662057D10 CHIP RES 27 K OHMS 5%
R1425 0662057D10 CHIP RES 27 K OHMS 5%
R1440 0662057A25 CHIP RES 100 OHMS 5%
R1442 0662057A25 CHIP RES 100 OHMS 5%
R1443 0662057A49 CHIP RES 1000 OHMS 5%
R1444 0662057A33 CHIP RES 220 OHMS 5%
R1445 0662057A68 CHIP RES 6200 OHMS 5%
R1447 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R1449 0611079A64 RES FIXED CHIP 390 5 1/
10W A/P
R1450 0683962T71 RES CHIP 820 5-1
R1451 0662057K31 CHIP RES 180 OHMS 5%
R1453 0662057K31 CHIP RES 180 OHMS 5%
R1454 0662057K31 CHIP RES 180 OHMS 5%
Circuit
Ref
Motorola
Part No.
Description
R1455 0662057K31 CHIP RES 180 OHMS 5%
R1457 0662057K01 CHIP RES 10 OHMS 5%
R1458 0611079A64 RES FIXED CHIP 390 5 1/
10W A/P
R1459 0611079A64 RES FIXED CHIP 390 5 1/
10W A/P
R1460 0680106R01 RES CHIP
R1463 0662057A75 CHIP RES 12K OHMS 5%
R1464 0662057A61 CHIP RES 3300 OHMS 5%
R1465 0662057A61 CHIP RES 3300 OHMS 5%
R1469 0662057C01 CHIP RESISTOR 0
OHMS+050 OHMS
R1472 0662057A73 CHIP RES 10K OHMS 5%
R1473 0680194M01 RES 10 OHMS 5% 1W
R1474 0680194M01 RES 10 OHMS 5% 1W
R1475 0680194M01 RES 10 OHMS 5% 1W
R1476 0680194M01 RES 10 OHMS 5% 1W
R1477 0662057A61 CHIP RES 3300 OHMS 5%
R1478 0662057A73 CHIP RES 10K OHMS 5%
R1479 0662057A61 CHIP RES 3300 OHMS 5%
R1480 0662057D10 CHIP RES 27 K OHMS 5%
R1482 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R1483 0662057A34 CHIP RES 240 OHMS 5%
R1484 0662057A49 CHIP RES 1000 OHMS 5%
R1501 0662057A45 CHIP RES 680 OHMS 5%
R1502 0662057C67 CHIP RES 470 OHMS 5%
R1503 0662057A61 CHIP RES 3300 OHMS 5%
R1504 0662057A73 CHIP RES 10K OHMS 5%
R1505 0662057A69 CHIP RES 6800 OHMS 5%
R1506 0662057A87 CHIP RES 39K OHMS 5%
R1507 0662057A49 CHIP RES 1000 OHMS 5%
R1508 0662057R19 CHIP RES 100 OHMS 1%
R1509 0662057P95 RES CHIP 100.0K 1% 30X60
R1511 0662057P95 RES CHIP 100.0K 1% 30X60
R1513 0662057C76 CHIP RES 1100 OHMS 5%
R1514 0662057A97 CHIP RES 100K OHMS 5%
R1515 0662057A49 CHIP RES 1000 OHMS 5%
R1516 0662057C71 CHIP RES 680 OHMS 5%
R1517 0662057C71 CHIP RES 680 OHMS 5%
R1518 0662057A61 CHIP RES 3300 OHMS 5%
R1519 0662057C71 CHIP RES 680 OHMS 5%
R1522 0662057A73 CHIP RES 10K OHMS 5%
R1524 0662057C71 CHIP RES 680 OHMS 5%
R1526 0662057A97 CHIP RES 100K OHMS 5%
R1527 0662057A97 CHIP RES 100K OHMS 5%
R1528 0662057A80 CHIP RES 20K OHMS 5%
R1532 0662057A95 CHIP RES 82K OHMS 5%
R1533 0662057A73 CHIP RES 10K OHMS 5%
R1535 0662057C01 CHIP RESISTOR 0
OHMS+050 OHMS
Circuit
Ref
Motorola
Part No.
Description
