Low Band Range 3 (42–50 MHz) PCBs, Schematics, and Parts Lists Section 7: 4-95
6881091C63-F
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field-replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
†
Replacement boards must be ordered from
CCSD (formerly AAD) using the number shown
in the model charts in Section 1. Boards are not
orderable using the 84-prefixed number.
R1537 0662057A90 CHIP RES 51K OHMS 5%
R1541 0662057A68 CHIP RES 6200 OHMS 5%
R1542 0662057A49 CHIP RES 1000 OHMS 5%
R1543 0662057A49 CHIP RES 1000 OHMS 5%
R1544 0662057A90 CHIP RES 51K OHMS 5%
R1545 0662057A65 CHIP RES 4700 OHMS 5%
R1601 0662057A73 CHIP RES 10K OHMS 5%
R1602 0662057A65 CHIP RES 4700 OHMS 5%
R1604 0662057A49 CHIP RES 1000 OHMS 5%
R1605 0662057B10 CHIP RES 330K OHMS 5%
R1606 0662057B02 CHIP RES 150K OHMS 5%
R1607 0662057B19 CHIP RES 750K OHMS 5%
R1608 0662057A57 CHIP RES 2200 OHMS 5%
R1609 0662057A73 CHIP RES 10K OHMS 5%
R1610 0662057A82 CHIP RES 24K OHMS 5%
R1611 0662057A49 CHIP RES 1000 OHMS 5%
R1612 0662057A25 CHIP RES 100 OHMS 5%
R1613 0662057A59 CHIP RES 2700 OHMS 5%
R1614 0662057A49 CHIP RES 1000 OHMS 5%
R1615 0662057A49 CHIP RES 1000 OHMS 5%
R1616 0662057A33 CHIP RES 220 OHMS 5%
R1617 0662057A57 CHIP RES 2200 OHMS 5%
R1620 0662057A51 CHIP RES 1200 OHMS 5%
R1621 0662057A68 CHIP RES 6200 OHMS 5%
R1622 0662057A49 CHIP RES 1000 OHMS 5%
R1626 0662057A18 CHIP RES 51 OHMS 5%
R1627 0662057A73 CHIP RES 10K OHMS 5%
R1628 0662057A55 CHIP RES 1800 OHMS 5%
R1629 0662057A67 CHIP RES 5600 OHMS 5%
R1630 0662057A53 CHIP RES 1500 OHMS 5%
R1631 0662057A18 CHIP RES 51 OHMS 5%
R1632 0662057A82 CHIP RES 24K OHMS 5%
R1635 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R1636 0662057A42 CHIP RES 510 OHMS 5%
R1637 0662057A59 CHIP RES 2700 OHMS 5%
R1638 0662057A55 CHIP RES 1800 OHMS 5%
U0101 5185143000 HC11FL0 (3V) ASIC MICRO-
P
U0111 5116648H01 128KBIT SERIAL SPI BUS
EEPROM
U0121 5115034H01 IC FLASH 4MBIT
U0122 5185748L01 32K X 8 SRAM 28PIN TSOP
U0141 5113805A30 IC 1 OF 8 DCDR/DEMUX
74HC138
U0211 5183222M49 IC AMP __3403_
U0221 5115062H01 IC ASFIC_CMP
U0251 5184704M60 IC CMOS 04M60 ANALOG
U0271 5102463J95 AUDIO PA TDA1519C
U0611 5183308X01 “IC, LM2941, TO DRPOUT
RGTR”
Circuit
Ref
Motorola
Part No.
Description
U0641 5183308X01 “IC, LM2941, TO DRPOUT
RGTR”
U0651 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U0652 5113815A02 IC UNDERVOLT SENSING
CKT
U1001 4809939C05 TSTR DUAL NPN/PNP UMH
5
U1051 5108278X01 MIXER MINICIRCUITS ADE-
1H
U1101 5102463J52 MC74HC4066D QUAD ANA-
LOG SWITCH
U1102 5102463J52 MC74HC4066D QUAD ANA-
LOG SWITCH
U1103 5115281H01 FM IF IC SA616 FROM
PHILIPS
U1201 5185177Y01 IC TESTED AT25016 48 PIN
W18
U1250 5185963A33 IC ADJUSTABLE VOLTAGE
MINI
U1377 4809939C05 TSTR DUAL NPN/PNP UMH
5
U1378 4809939C05 TSTR DUAL NPN/PNP UMH
5
U1401 5115678H01 VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
U1402 5113818A03 IC HIGH PERFORMANCE
SING SPLY
U1501 5185963A15 IC TEMPERTURE SENSOR
1M50C
U1502 5109731C21 IC OP AMP LM6142BIM 8SO
U1503 5185765B26 IC PWR CTRL IN MOS20
U1601 5180929W01 LINEAR INT CIRCUIT
VR0151 4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR0501 4813979C11 “DIODE,SUPR,QUAD 20 V
ZEN, PB-FREE”
VR0503 4813979C11 “DIODE,SUPR,QUAD 20 V
ZEN, PB-FREE”
VR0504 4813830A40 DIODE 33V 5% 225MW
MMBZ5257B_
VR0505 4813979C11 “DIODE,SUPR,QUAD 20 V
ZEN, PB-FREE”
VR0509 4813830A40 DIODE 33V 5% 225MW
MMBZ5257B_
VR0510 4813830A40 DIODE 33V 5% 225MW
MMBZ5257B_
VR0537 4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
VR0541 4813830A27 DIODE 14V 5% 225MW
MMBZ5244B_
Circuit
Ref
Motorola
Part No.
Description
VR0601 4813832C77 TRANS SUP. 24V HIGH PWR
VR0621 4813830A15 DIODE 5.6V 5% 225MW
MMBZ5232B_
Y0131 4816169H01 CRYSTAL 38.4KHZ
*Y1101 4880908W08 10.245 MHZ XTAL
Y1102 9186145B02 CER.DISCR.
CDBCA455CX36-TC
Y1201 4880114R04 CRYSTAL 16.8 MHZ
Circuit
Ref
Motorola
Part No.
Description
