Motorola Pro3100 Detailed Service Manual

VHF (136–174 MHz) 25–45 W LDMOS PCB 8471234L02, Schematics, and Parts Lists Section 11: 4-21
6881091C63-F
C3512 2113945L25 CAP 1000 PF
C3514 2113945G45 CAP 10000 PF
C3515 2113945L33 CAP 2200 PF
C3523 2113944F07 CAP 1000 PF
C3527 2111078B37 CAP 62 PF
C3528 2111078B37 CAP 62 PF
C3529 2111078B41 CAP 91 PF
C3530 2111078B08 CAP 6.2 PF
C3531 2111078B08 CAP 6.2 PF
C3543 2111078B33 CAP 43 PF
C3544 2113945G91 CAP 100000 PF
C3545 2113945G45 CAP 10000 PF
C3546 2113955E01 CAP 1 UF
C3550 2113944F07 CAP 1000 PF
C3551 2113944C79 CAP 16 PF
C3555 2113944F07 CAP 1000 PF
C3561 2111078B59 CAP 470 PF
C3563 2111078B45 CAP 130 PF
C3564 2111078B12 CAP 9.1 PF
C3565 2111078B32 CAP 39 PF
C3566 2111078B33 CAP 43 PF
C3567 2111078B31 CAP 36 PF
C3568 2111078B14 CAP 11 PF
C3569 2113945L33 CAP 2200 PF
C3570 2111078B41 CAP 91 PF
C3574 2113944C46 CAP 120 PF
C3575 2113944C46 CAP 120 PF
C3576 2113944C46 CAP 120 PF
C3578 2113944C46 CAP 120 PF
D3000 4813978C02 DIODE DUAL 70V 5B
D3001 4885094Y01 DIODE VARACTOR ISV228
D3003 4815048H01 DIODE MMBD353 DUAL
D3004 4885094Y01 DIODE VARACTOR ISV228
D3011 4813974A06 DIODE PIN SOT-23
D3031 4886143B01
WM MIXER QUAD RING
DIODE
D3101 4815048H01 DIODE MMBD353 DUAL
D3201 4815011H01 DIODE TRIPLE
D3221 4813974A05 DIODE MMBD301L
D3341 4885094Y01 DIODE VARACTOR ISV228
D3361 4885094Y01 DIODE VARACTOR ISV228
D3362 4885055Y01 DIODE VARACTOR 15V
D3402 4813978C02 DIODE DUAL 70V 5B
D3451 4813974A21 DIODE BAS70-04
D3452 4813974A21 DIODE BAS70-04
D3471 4802482J02 DIODE PIN SMD
D3472 4802482J02 DIODE PIN SMD
Circuit
Ref
Motorola Part
No.
Description
FL3101 9180112R16 44.85 MHZ XTAL FILTER
FL3102 9180112R16 44.85 MHZ XTAL FILTER
FL3111 9115811H01 6 ELEMENT XTAL FILTER
FL3112 9115811H04 6 ELEMENT XTAL FILTER
FL3114 9180468V06 4 ELEMENT XTAL FILTER
FL3115 9115811H02 6 ELEMENT XTAL FILTER
J3401 0986166B01 BNC RF CONNECTOR
L3002 2414032D23 IDCTR 470 NH
L3025 2414032D17 IDCTR 150 NH
L3031 2414032D24 IDCTR 560 NH
L3032 2414032D17 IDCTR 150 NH
L3101 2414032D25 IDCTR 620 NH
L3111 2414032D25 IDCTR 620 NH
L3112 2414032D25 IDCTR 620 NH
L3124 2414032B68 IDCTR 1 UH
L3201 2414017Q42 IDCTR 390 NH
L3231 2414017Q20 IDCTR 2.2 UH
L3301 2414032B44 IDCTR 18 NH
L3302 2414032B53 IDCTR 100 NH
L3317 2414032F28 IDCTR 33 NH
L3318 2414032F34 IDCTR 100 NH
L3331 2414032F32 IDCTR 68 NH
L3332 2414032F15 IDCTR 100 NH
L3333 2414017Q47 IDCTR 1 UH
L3341 2415385H01 IDCTR 8 NH
L3343 2414032B56 IDCTR 180 NH
L3344 2414032B68 IDCTR 1 UH
L3345 2414032B68 IDCTR 1 UH
L3346 2415385H07 IDCTR 35.5 NH
L3351 2414032B68 IDCTR 1 UH
L3361 2414032B50 IDCTR 56 NH
L3362 2414032B51 IDCTR 68 NH
L3363 2414032B50 IDCTR 56 NH
L3364 2414032B68 IDCTR 1 UH
L3401 2460591A01 IDCTR 4.22 NH
L3402 2415954H02 IDCTR BEAD CHIP
L3403 2414032D13 IDCTR 68 NH
L3411 2414032D13 IDCTR 68 NH
L3412 2414032B42 IDCTR 12 NH
L3414 2460591A11 IDCTR 7.66 NH
L3421 2415954H02 IDCTR BEAD CHIP
L3422 2460591C23 IDCTR 13.85 NH
L3436 2415954H02 IDCTR BEAD CHIP
L3437 2460592A01 IDCTR 17 NH
L3443 2485873L01 IDCTR 18 NH
L3471 2414032B69 IDCTR 1200 NH
L3500 2414032B42 IDCTR 12 NH
Circuit
Ref
Motorola Part
No.
Description
L3510 2414032B69 IDCTR 1200 NH
L3511 2485873L05 IDCTR 48 NH
L3512 2460592B01 IDCTR 51 NH
L3513 2460592B01 IDCTR 51 NH
L3514 2460592B01 IDCTR 51 NH
L3515 2485873L05 IDCTR 48 NH
M3421 2686201B02 HEATSPREADER
Q1503 4813973M07 TSTR MMBT3904
Q3001 4802197J95 TSTR PBR941
Q3002 4813973A13 TSTR PNP TO-236
Q3021 4816097H01 TSTR FMC2 RH
Q3101 4802197J95 TSTR PBR941
Q3102 4802197J95 TSTR PBR941
Q3141 4813973M07 TSTR MMBT3904
Q3151 4813973A42 TSTR NPN SC-59
Q3152 4813973A42 TSTR NPN SC-59
Q3221 4813973A42 TSTR NPN SC-59
Q3301 4802197J95 TSTR PBR941
Q3303 4815055H01 TSTR UMC5NT2G DUAL
Q3304 4805218N63 TSTR BFQ67W
Q3411 4816097H01 TSTR FMC2 RH
Q3421
4813976A04/
††
48012032001
TSTR MRF1518 LDMOS
Q3422 4813973A42 TSTR NPN 47K
Q3441
4816121H01/
††
48012035001
LD MOS SMT 55W 520MHZ
12V
Q3442 4813973A42 TSTR NPN 47K
Q3471 4813973A42 TSTR NPN 47K
Q3472 4816049H01 SOT TRANS
Q4451 4813973M07 TSTR MMBT3904
Q4452 4813973M07 TSTR MMBT3904
Q4455 4871309S01 XSTR SI3455D
Q4456 4816000H01 TSTR DTC114YETL
Q4457 4813973M07 TSTR MMBT3904
R3000 0613952H77 RES 1500 OHM
R3001 0613952J25 RES 100K OHM
R3002 0613952H67 RES 560 OHM
R3003 0613952H73 RES 1000 OHM
R3004 0613952H77 RES 1500 OHM
R3006 0613952J01 RES 10K OHM
R3009 0613952J25 RES 100K OHM
R3010 0613952H69 RES 680 OHM
R3011 0613952H89 RES 4700 OHM
R3012 0613952H73 RES 1000 OHM
R3013 0613952H85 RES 3300 OHM
R3014 0613952H42 RES 51 OHM
Circuit
Ref
Motorola Part
No.
Description
R3015 0613952H25 RES 10 OHM
R3016 0613952H25 RES 10 OHM
R3018 0613952H57 RES 220 OHM
R3019 0613952J17 RES 47K OHM
R3021 0613952H67 RES 560 OHM
R3024 0613952H63 RES 390 OHM
R3025 0613952H77 RES 1500 OHM
R3026 0613952J01 RES 10K OHM
R3027 0613952J01 RES 10K OHM
R3028 0613952H63 RES 390 OHM
R3031 0613952H42 RES 51 OHM
R3033 0613952G67 RES 0 OHM
R3101 0613952J03 RES 12K OHM
R3102 0613952H25 RES 10 OHM
R3105 0613952H49 RES 100 OHM
R3106 0613952J11 RES 27K OHM
R3107 0613952H82 RES 2400 OHM
R3108 0613952H75 RES 1200 OHM
R3111 0613952J03 RES 12K OHM
R3112 0613952H25 RES 10 OHM
R3113 0613952H61 RES 330 OHM
R3115 0613952H63 RES 390 OHM
R3116 0613952H81 RES 2200 OHM
R3117 0613952J11 RES 27K OHM
R3118 0613952H82 RES 2400 OHM
R3124 0613952H73 RES 1000 OHM
R3130 0613952H42 RES 51 OHM
R3132 0613952J05 RES 15K OHM
R3133 0613952H89 RES 4700 OHM
R3134 0613952H95 RES 8200 OHM
R3135 0613952H75 RES 1200 OHM
R3141 0613952H63 RES 390 OHM
R3142 0613952H79 RES 1800 OHM
R3144 0613952H82 RES 2400 OHM
R3145 0613952H85 RES 3300 OHM
R3146 0613952H69 RES 680 OHM
R3147 0613952J03 RES 12K OHM
R3151 0613952J01 RES 10K OHM
R3152 0613952J01 RES 10K OHM
R3153 0613952J01 RES 10K OHM
R3154 0613952J01 RES 10K OHM
R3201 0613952H41 RES 47 OHM
R3203 0613952H41 RES 47 OHM
R3204 0613952H41 RES 47 OHM
R3211 0613952G67 RES 0 OHM
R3221 0613952H63 RES 390 OHM
R3222 0613952H69 RES 680 OHM
Circuit
Ref
Motorola Part
No.
Description
