Motorola Pro3100 Detailed Service Manual

Section 11: 4-22 VHF (136–174 MHz) 25–45 W LDMOS PCB 8471234L02, Schematics, and Parts Lists
6881091C63-F
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
††
Parts with Fab IC from Texas
R3223 0613952H49 RES 100 OHM
R3224 0613952J17 RES 47K OHM
R3225 0613952J17 RES 47K OHM
R3227 0613952J25 RES 100K OHM
R3241 0613952H49 RES 100 OHM
R3242 0613952G67 RES 0 OHM
R3251 0613952J31 RES 180K OHM
R3252 0613952J37 RES 330K OHM
R3261 0613952J17 RES 47K OHM
R3263 0613952H89 RES 4700 OHM
R3265 0613952G67 RES 0 OHM
R3301 0613952H46 RES 75 OHM
R3302 0613952H49 RES 100 OHM
R3303 0613952H81 RES 2200 OHM
R3304 0613952H73 RES 1000 OHM
R3308 0613952G67 RES 0 OHM
R3311 0613952H49 RES 100 OHM
R3316 0613952G67 RES 0 OHM
R3318 0613952H33 RES 22 OHM
R3321 0613952J01 RES 10K OHM
R3323 0613952H73 RES 1000 OHM
R3331 0613952H41 RES 47 OHM
R3335 0613952H37 RES 33 OHM
R3336 0613952J05 RES 15K OHM
R3341 0613952H57 RES 220 OHM
R3342 0613952H39 RES 39 OHM
R3343 0613952H49 RES 100 OHM
R3351 0613952J08 RES 20K OHM
R3352 0613952J03 RES 12K OHM
R3353 0613952J25 RES 100K OHM
R3354 0613952J29 RES 150K OHM
R3355 0613952J08 RES 20K OHM
R3356 0613952J03 RES 12K OHM
R3361 0613952H57 RES 220 OHM
R3362 0613952H41 RES 47 OHM
R3364 0613952J17 RES 47K OHM
R3400 0613952H65 RES 470 OHM
R3401 0613952H60 RES 300 OHM
R3402 0613952H29 RES 15 OHM
R3403 0613952H60 RES 300 OHM
R3405 0613952H49 RES 100 OHM
R3406 0613952J25 RES 100K OHM
R3407 0613958H18 RES 5.1 OHM
R3408 0613952J17 RES 47K OHM
R3411 0613952H70 RES 750 OHM
R3412 0613952H73 RES 1000 OHM
R3413 0613952H85 RES 3300 OHM
Circuit
Ref
Motorola Part
No.
Description
R3414 0613959Y51 RES 120 OHM
R3415 0613952H38 RES 36 OHM
R3416 0613952H38 RES 36 OHM
R3417 0613952J11 RES 27K OHM
R3418 0613952J09 RES 22K OHM
R3421 0613952J15 RES 39K OHM
R3422 0613952H81 RES 2200 OHM
R3423 0613952J15 RES 39K OHM
R3424 0613958H11 RES 2.7 OHM
R3425 0613958H11 RES 2.7 OHM
R3426 0613958H11 RES 2.7 OHM
R3427 0613958H11 RES 2.7 OHM
R3428 0613952H82 RES 2400 OHM
R3431 0613959Y42 RES 51 OHM
R3432 0613959Y42 RES 51 OHM
R3441 0613952J15 RES 39K OHM
R3442 0613952H81 RES 2200 OHM
R3443 0613952J15 RES 39K OHM
R3444 0613958H11 RES 2.7 OHM
R3445 0613952H82 RES 2400 OHM
R3446 0613952G67 RES 0 OHM
R3450 0613959Y51 RES 120 OHM
R3454 0613952J15 RES 39K OHM
R3455 0613952J25 RES 100K OHM
R3460 0613958J74 RES 0 OHM
R3461 0613959Y44 RES 62 OHM
R3471 0613952H65 RES 470 OHM
R3473 0613959Y42 RES 51 OHM
R3474 0613959Y42 RES 51 OHM
R3475 0613952J01 RES 10K OHM
R3501 0613952H93 RES 6800 OHM
R3502 0613952J15 RES 39K OHM
R3504 0613952J01 RES 10K OHM
R3505 0613952J36 RES 300K OHM
R3507 0613952J08 RES 20K OHM
R3508 0613952J25 RES 100K OHM
R3509 0613952H73 RES 1000 OHM
R3510 0613958J74 RES 0 OHM
R3511 0613958C01 RES 100 OHM
R3512 0613952F01 RES 100K OHM
R3515 0613952F01 RES 100K OHM
R3517 0613958H86 RES 3600 OHM
R3518 0671463L01 RES 0.01 OHM
R3525 0613958H11 RES 2.7 OHM
R3526 0613958H11 RES 2.7 OHM
R3527 0613958H11 RES 2.7 OHM
R3540 0613958H73 RES 1000 OHM
Circuit
Ref
Motorola Part
No.
Description
R3541 0613958J74 RES 0 OHM
R3545 0613952J17 RES 47K OHM
R3555 0613958J01 RES 10K OHM
R3556 0613952J33 RES 220K OHM
R3560 0613952G67 RES 0 OHM
R3561 0613952J47 RES 820K OHM
R3562 0613958J49 RES 1M OHM
R3563 0613958J49 RES 1M OHM
R3564 0613952J25 RES 100K OHM
R3565 0613952H82 RES 2400 OHM
R3566 0613952J25 RES 100K OHM
R3567 0613952H82 RES 2400 OHM
R3568 0613952J25 RES 100K OHM
R3569 0613952H83 RES 2700 OHM
R3576 0613952J25 RES 100K OHM
R3577 0613952J25 RES 100K OHM
R3578 0613952J25 RES 100K OHM
R3579 0613952H82 RES 2400 OHM
R3580 2415347H01 IDCTR 1 UH
R3581 0613952J25 RES 100K OHM
RT3501 0671668L01 TERMISTOR 50K OHM
SH3301 2602641Y03 SHIELD VCO
T3001 2566506A01 BALUN TRANSFORMER
T3002 2566506A02 BALUN TRANSFORMER
U3101 5115281H01 IC FM IF SA616
U3111 5185291Y01 IC SOIC14
U3115 5185291Y01 IC SOIC14
U3201 5185177Y01 IC FRACTN AT25016
U3211 5115026H01 IC LINEAR VOLTAGE REG
U3301 5171121L01 IC PKG DIE VCO BUFFER
U3401
5115678H01/
††
51012101001
IC RF AMP TSSOP16EP
U3402 5115344H01 IC OP AMP LM6142BIM 8SO
U3501 5185765B26 IC PWR CTRL TQFP32
U3502 5115022H01
IC TEMPERATURE SENSOR
1M50C
U3503 5115344H01 IC OP AMP LM6142BIM 8SO
VR3471 4813977M11 DIODE MBZ5253B
Y3101 4802245J84 XTAL 44.395 MHZ
Y3102 9186145B02
CER DISC CDBCA455CX36-
TC
Y3263 4816142H01 XTAL OSC 16.8 MHZ
Circuit
Ref
Motorola Part
No.
Description
