Section 12: 4-22 UHF Band 1 (403–470 MHz) 25–40 W LDMOS PCB 8471223L02, Schematics, and Parts Lists
6881091C63-F
C4459 2113944F01 CAP 100 PF
C4462 2113944C37 CAP 39 PF
C4469 2113944F01 CAP 100 PF
C4472 2111078B31 CAP 36 PF
C4473 2113944C45 CAP 100 PF
C4474 2113944C31 CAP 12 PF
C4475 2113944C13 CAP 2 PF
C4478 2113945G21 CAP 1000 PF
C4479 2113944C45 CAP 100 PF
C4481 2113945G32 CAP 3000 PF
C4483 2113944F01 CAP 100 PF
C4484 2113944C82 CAP 30 PF
C4485 2113944C82 CAP 30 PF
C4487 2111078B01 CAP 3.3 PF
C4488 2113944C45 CAP 100 PF
C4491 2111078B01 CAP 3.3 PF
C4492 2111078B42 CAP 100 PF
C4494 2180464E63 CAP 10 PF
C4495 2113945G21 CAP 1000 PF
C4496 2111078B08 CAP 6.2 PF
C4497 2113945G21 CAP 1000 PF
C4498 2111078B08 CAP 6.2 PF
C4499 2113944C45 CAP 100 PF
C4502 2113945C18 CAP 12 UF
C4503 2113945L17 CAP 470 PF
C4504 2113945L49 CAP 1 UF
C4505 2313960B01 CAP 1 UF
C4506 2113945L33 CAP 2200 PF
C4507 2113944C45 CAP 100 PF
C4510 2111078B31 CAP 36 PF
C4602 2113945G57 CAP 33000 PF
C4629 2113944C45 CAP 100 PF
C4630 2113945C31 CAP 0.1 UF
C4631 2113945C31 CAP 0.1 UF
C4632 2113944C45 CAP 100 PF
C4701 2113944C45 CAP 100 PF
C4704 2113944C45 CAP 100 PF
C4706 2113944C45 CAP 100 PF
C4707 2113944C02 CAP 220 PF
C4708 2113945G91 CAP 100000 PF
C4709 2113945G91 CAP 100000 PF
CR4301 4885094Y01 DIODE VARACTOR ISV228
CR4302 4885055Y01 DIODE VARACTOR 15V
CR4303 4885055Y01 DIODE VARACTOR 15V
CR4311 4815322H01 DIODE VARACTOR BB153
CR4321 4885055Y01 DIODE VARACTOR 15V
Circuit
Ref
Motorola
Part No.
Description
D3101 4815048H01 DIODE MMBD353 DUAL
D4001 4885055Y01 DIODE VARACTOR 15V
D4002 4885055Y01 DIODE VARACTOR 15V
D4003 4815048H01 DIODE MMBD353 DUAL
D4004 4885055Y01 DIODE VARACTOR 15V
D4005 4885055Y01 DIODE VARACTOR 15V
D4006 4813974A06 DIODE PIN SOT-23
D4007 4813978C02 DIODE DUAL 70V 5B
D4051 4886143B01
WM MIXER QUAD RING
DIODE
D4201 4815011H01 DIODE TRIPLE
D4221 4813974A05 DIODE MMBD301L
D4451 4813974A05 DIODE MMBD301L
D4452 4813974A05 DIODE MMBD301L
D4453 4813974A05 DIODE MMBD301L
D4471 4802482J02 DIODE PIN SMD
D4472 4802482J02 DIODE PIN SMD
FL3101 9180112R16 44.85 MHZ XTAL FILTER
FL3102 9180112R16 44.85 MHZ XTAL FILTER
FL3111 9115811H01 6 ELEMENT XTAL FILTER
FL3112 9115811H04 6 ELEMENT XTAL FILTER
FL3114 9180468V06 4 ELEMENT XTAL FILTER
FL3115 9115811H02 6 ELEMENT XTAL FILTER
J4401 0986166B01 BNC RF CONNECTOR
L3101 2414032D25 IDCTR 620 NH
L3111 2414032D25 IDCTR 620 NH
L3112 2414032D25 IDCTR 620 NH
L3124 2414032B68 IDCTR 1 UH
L4003 2414032D23 IDCTR 470 NH
L4006 2414032F24 IDCTR 15 NH
L4008 2414032D23 IDCTR 470 NH
L4051 2414032D17 IDCTR 150 NH
L4053 2414032B46 IDCTR 27 NH
L4054 2414032B43 IDCTR 15 NH
L4201 2414017Q42 IDCTR 390 NH
L4221 2414032L25 IDCTR 12 UH
L4231 2414017Q20 IDCTR 2.2 UH
L4301 2414032D22 IDCTR 390 NH
L4302 2414032D22 IDCTR 390 NH
L4303 2460593C01 IDCTR 12.21 NH
L4304 2414032D22 IDCTR 390 NH
L4305 2414032D22 IDCTR 390 NH
L4311 2414032D22 IDCTR 390 NH
L4312 2460593C01 IDCTR 12.21 NH
L4313 2414032D22 IDCTR 390 NH
L4331 2414032D09 IDCTR 33 NH
Circuit
Ref
Motorola
Part No.
Description
L4333 2414032D22 IDCTR 390 NH
L4361 2414032D09 IDCTR 33 NH
L4362 2414032D09 IDCTR 33 NH
L4371 2414032D13 IDCTR 68 NH
L4401 2460591B04 IDCTR 11.03 NH
L4402 2415954H02 IDCTR BEAD CHIP
L4403 2414032D22 IDCTR 390 NH
L4411 2414032D22 IDCTR 390 NH
L4421 2415954H02 IDCTR BEAD CHIP
L4436 2415954H02 IDCTR BEAD CHIP
L4437 2460592A01 IDCTR 17 NH
L4438 2460592A01 IDCTR 17 NH
L4472 2460592A01 IDCTR 17 NH
L4473 2460591N36 IDCTR 43.67 NH
L4489 2460591B77 IDCTR 13.90 NH
L4490 2460591B77 IDCTR 13.90 NH
L4491 2460592A01 IDCTR 17 NH
L4492 2460592A01 IDCTR 17 NH
L4493 2460592A01 IDCTR 17 NH
L4541 2415954H02 IDCTR BEAD CHIP
L4543 2460591C23 IDCTR 13.85 NH
M3421 2686201B02 HEATSPREADER
Q3101 4802197J95 TSTR PBR941
Q3102 4802197J95 TSTR PBR941
Q3141 4813973M07 TSTR MMBT3904
Q3151 4813973A42 TSTR NPN SC-59
Q3152 4813973A42 TSTR NPN SC-59
Q4002 4813973A13 TSTR PNP TO-236
Q4003 4802197J95 TSTR PBR941
Q4004 4816097H01 TSTR FMC2 RH
Q4221 4813973A42 TSTR NPN SC-59
Q4301 4805218N63 TSTR BFQ67W
Q4332 4802197J95 TSTR PBR941
Q4333 4815055H01 TSTR UMC5NT2G DUAL
Q4421
4813976A04/
††
48012032001
TSTR MRF1518 LDMOS
Q4441
4816022H01/
††
48012036001
TSTR MRF1570 LDMOS
Q4451 4813973M07 TSTR MMBT3904
Q4452 4813973M07 TSTR MMBT3904
Q4453 4813973M07 TSTR MMBT3904
Q4454 4813973M07 TSTR MMBT3904
Q4455 4871309S01 XSTR SI3455D
Q4456 4816000H01 TSTR DTC114YETL
Q4457 4813973M07 TSTR MMBT3904
Q4471 4813973A42 TSTR NPN SC-59
Circuit
Ref
Motorola
Part No.
Description
Q4472 4816049H01 TSTR 2SB1132 BIPOLAR
Q4473 4813973M07 TSTR MMBT3904
R3101 0613952J03 RES 12K OHM
R3102 0613952H25 RES 10 OHM
R3105 0613952H49 RES 100 OHM
R3106 0613952J11 RES 27K OHM
R3107 0613952H82 RES 2400 OHM
R3108 0613952H75 RES 1200 OHM
R3111 0613952J03 RES 12K OHM
R3112 0613952H25 RES 10 OHM
R3113 0613952H61 RES 330 OHM
R3115 0613952H63 RES 390 OHM
R3116 0613952H81 RES 2200 OHM
R3117 0613952J11 RES 27K OHM
R3118 0613952H82 RES 2400 OHM
R3124 0613952H73 RES 1000 OHM
R3130 0613952H42 RES 51 OHM
R3132 0613952J05 RES 15K OHM
R3133 0613952H89 RES 4700 OHM
R3134 0613952H95 RES 8200 OHM
R3135 0613952H75 RES 1200 OHM
R3141 0613952H63 RES 390 OHM
R3142 0613952H79 RES 1800 OHM
R3144 0613952H82 RES 2400 OHM
R3145 0613952H85 RES 3300 OHM
R3146 0613952H69 RES 680 OHM
R3147 0613952J03 RES 12K OHM
R3148 2113944C45 CAP 100 PF
R3151 0613952J01 RES 10K OHM
R3152 0613952J01 RES 10K OHM
R3153 0613952J01 RES 10K OHM
R3154 0613952J01 RES 10K OHM
R4001 0613952J25 RES 100K OHM
R4002 0613952H61 RES 330 OHM
R4003 0613952H87 RES 3900 OHM
R4004 0613952H83 RES 2700 OHM
R4005 0613952J01 RES 10K OHM
R4007 0613952H49 RES 100 OHM
R4012 0613952J25 RES 100K OHM
R4013 0613952H59 RES 270 OHM
R4014 0613952H25 RES 10 OHM
R4016 0613952H85 RES 3300 OHM
R4018 0613952H85 RES 3300 OHM
R4022 0613952G67 RES 0 OHM
R4051 0613952H42 RES 51 OHM
R4052 0613952G67 RES 0 OHM
Circuit
Ref
Motorola
Part No.
Description
