Motorola Pro3100 Detailed Service Manual

UHF Band 1 (403–470 MHz) 25–40 W LDMOS PCB 8471223L02, Schematics, and Parts Lists Section 12: 4-23
6881091C63-F
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
††
Parts with Fab IC from Texas
R4060 0613952J37 RES 330K OHM
R4061 0613952J01 RES 10K OHM
R4062 0613952H77 RES 1500 OHM
R4063 0613952H63 RES 390 OHM
R4064 0613952G67 RES 0 OHM
R4068 0613952H77 RES 1500 OHM
R4069 0613952H73 RES 1000 OHM
R4070 0613952H63 RES 390 OHM
R4071 0613952J01 RES 10K OHM
R4072 0613952J01 RES 10K OHM
R4201 0613952H53 RES 150 OHM
R4203 0613952H41 RES 47 OHM
R4204 0613952H41 RES 47 OHM
R4211 0613952G67 RES 0 OHM
R4221 0613952H53 RES 150 OHM
R4222 0613952H66 RES 510 OHM
R4223 0613952H45 RES 68 OHM
R4224 0613952J17 RES 47K OHM
R4225 0613952J17 RES 47K OHM
R4228 0613952J01 RES 10K OHM
R4241 0613952H57 RES 220 OHM
R4251 0613952J15 RES 39K OHM
R4252 0613952J12 RES 30K OHM
R4261 0613952J17 RES 47K OHM
R4263 0613952H49 RES 100 OHM
R4301 0613952H91 RES 5600 OHM
R4302 0613952J01 RES 10K OHM
R4303 0613952H36 RES 30 OHM
R4304 0613952H55 RES 180 OHM
R4305 0613952H25 RES 10 OHM
R4311 0613952H94 RES 7500 OHM
R4312 0613952H91 RES 5600 OHM
R4313 0613952H36 RES 30 OHM
R4314 0613952H59 RES 270 OHM
R4315 0613952G67 RES 0 OHM
R4321 0613952J19 RES 56K OHM
R4322 0613952J01 RES 10K OHM
R4323 0613952J25 RES 100K OHM
R4331 0613952H33 RES 22 OHM
R4341 0613952G67 RES 0 OHM
R4342 0613952H81 RES 2200 OHM
R4343 0613952H73 RES 1000 OHM
R4344 0613952H25 RES 10 OHM
R4346 0613952J01 RES 10K OHM
R4347 0613952G67 RES 0 OHM
R4360 0613952H59 RES 270 OHM
Circuit
Ref
Motorola
Part No.
Description
R4361 0613952H55 RES 180 OHM
R4362 0613952H25 RES 10 OHM
R4363 0613952H73 RES 1000 OHM
R4381 0613952H65 RES 470 OHM
R4401 0613952H60 RES 300 OHM
R4402 0613952H29 RES 15 OHM
R4403 0613952H60 RES 300 OHM
R4405 0613952H56 RES 200 OHM
R4408 0613952J08 RES 20K OHM
R4409 0613952J25 RES 100K OHM
R4412 0613952H80 RES 2000 OHM
R4414 0613952H60 RES 300 OHM
R4415 0613952H39 RES 39 OHM
R4416 0613952H39 RES 39 OHM
R4422 0613958H68 RES 620 OHM
R4423 0613958H68 RES 620 OHM
R4424 0613958H68 RES 620 OHM
R4425 0613958H68 RES 620 OHM
R4428 0613952H79 RES 1800 OHM
R4457 0613959Y51 RES 120 OHM
R4473 0613952H88 RES 4300 OHM
R4474 0613952J25 RES 100K OHM
R4475 0613952G67 RES 0 OHM
R4480 0613952J01 RES 10K OHM
R4481 0613958H42 RES 51 OHM
R4482 0613952J36 RES 300K OHM
R4483 0613952J25 RES 100K OHM
R4484 0613952J20 RES 62K OHM
R4485 0613958H42 RES 51 OHM
R4486 0613958H42 RES 51 OHM
R4487 0613952J25 RES 100K OHM
R4488 0613952H83 RES 2700 OHM
R4489 0613958H42 RES 51 OHM
R4491 0613952J02 RES 11K OHM
R4492 0613952J01 RES 10K OHM
R4495 0613959Q42 RES 51 OHM
R4496 0613959Y47 RES 82 OHM
R4497 0613959Q42 RES 51 OHM
R4501 0613952H75 RES 1200 OHM
R4502 0613952J32 RES 200K OHM
R4503 0613952H87 RES 3900 OHM
R4504 0613952J01 RES 10K OHM
R4506 0613952J01 RES 10K OHM
R4507 0613952J01 RES 10K OHM
R4511 0613959Y42 RES 51 OHM
R4512 0613952H65 RES 470 OHM
Circuit
Ref
Motorola
Part No.
Description
R4513 0613952J01 RES 10K OHM
R4514 0613952H85 RES 3300 OHM
R4600 0613952J25 RES 100K OHM
R4601 0613952H83 RES 2700 OHM
R4602 0613952J25 RES 100K OHM
R4603 0613952H83 RES 2700 OHM
R4604 2415429H47 IDCTR 390 NH
R4605 0613952J29 RES 150K OHM
R4607 0613952J25 RES 100K OHM
R4608 0613952J25 RES 100K OHM
R4609 0613952J25 RES 100K OHM
R4610 0613952H83 RES 2700 OHM
R4631 0613952J17 RES 47K OHM
R4632 0613952J17 RES 47K OHM
R4634 0613952J25 RES 100K OHM
R4635 0613952J25 RES 100K OHM
SH4301 2602641Y03 SHIELD VCO
SH4302 2602641Y03 SHIELD VCO
T4051 2516149H01 XFMR MIXER 4-1
T4052 2516148H01 XMFR MIXER 5-1
U3101 5115281H01 IC FM IF SA616
U3111 5185291Y01 IC SOIC14
U3115 5185291Y01 IC SOIC14
U4201 5185177Y01 IC FRACTN AT25016
U4211 5115026H01 IC LINEAR VOLTAGE REG
U4301 5171121L01 IC PKG DIE VCO BUFFER
U4401
5115678H01/
††
51012101001
IC RF AMP TSSOP16EP
U4501 5185765B26 IC PWR CTRL TQFP32
U4502 5115022H01 IC TEMPERATURE SENSOR
VR4471 4813977M11 DIODE MBZ5232
VR4473 4813977M11 DIODE MBZ5232
Y3101 4802245J84 XTAL 44.395 MHZ
Y3102 9186145B02
CER DISC CDBCA455CX36-
TC
Y4262 4816142H01 XTAL OSC 16.8 MHZ
Circuit
Ref
Motorola
Part No.
Description
