Moxa Technologies AirWorks AWK-1131A User Manual

AirWorks AWK-1131A Web Console Configuration
3-42
Misc. Settings
Additional settings to help you manage your AWK-1131A are available on this page.
Reset button
Setting Description Factory Default
Always Enable The AWK-1131A’s Reset button works normally. Always enable
Disable the Factory
Reset Function after 60
Seconds
The AWK-1131A’s reset to default function will be inactive 60
seconds after the AWK-1131A finishes booting up.
Troubleshooting
This feature allows you to quickly obtain the current system status and provide diagnostics information to Moxa
engineers.
To export the current device information, click Export.
For cases where advanced troubleshooting is required, contact a Moxa engineer who can provide you with an
encrypted script file. The encrypted script file can capture additional details on the system.
To run the script, browse to and select the script file using Browse and click Run Script after you have filled
in the following details:
Setting Description
Diagnostic script Use the Browse button to select the Moxa diagnosis script file.
Export diagnostic results Select if you want to export:
• to a file
• to a TFTP server
TFTP server IP If you have selected the TFTP option, specify the IP address of the TFTP
server.
Diagnostic script name Displays the name of the script file
Last start time Displays the start time of the last script execution

Moxa Technologies AirWorks AWK-1131A Specifications

General

Brand	Moxa Technologies
Model	AirWorks AWK-1131A
Category	Wireless Access Point
Language	English
