Moxa Technologies NPort IA5150A User Manual

NPort IA5150A/IA5250A Series Configuring NPort Administrator
6-13
The second way is with Off-line COM Installation, without first connecting the NPort IA5150A/IA5250A to
the network. Off-line COM Mapping can decrease the system integrator’s effort by solving different field
problems. Via off-line installation, users can first process software installation for the host, and then install the
NPort IA5150A/IA5250A to different fields.
Use the following procedure to map COM ports:
1. On-line COM Mapping:
Connect NPort IA5150A/IA5250A to the network  Set NPort IA5150A/IA5250A to the proper IP address 
Map COMs to your host  Apply Change.
2. Off-line COM Mapping:
Map COMs to your host  Apply Change  Connect the NPort IA5150A/IA5250A to the network 
Configure NPort IA5150A/IA5250A’s IP address.
On-line COM Mapping
1. Broadcast Search for NPort IA5150A/IA5250As on the network.
2. Select the COM Mapping function group.
3. Add the target to which you would like to map COM ports.
4. The NPort IA5150A/IA5250A list that appears is the list generated by the previous Broadcast Search. Select
the NPort IA5150A/IA5250A to which you would like to map COM ports.
5. Select COM Settings to modify COM No., default setting, etc.

Moxa Technologies NPort IA5150A Specifications

General

Isolation	1.5 kV
Certification	CE, FCC
Serial interface type	RS-232/422/485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, Rtelnet, DNS, HTTP, SMTP, SNTP, IGMP
Connectivity LEDs	Yes
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	12 - 48 V
Safety	UL-508

Weight and Dimensions

Weight	475 g
Dimensions (WxDxH)	36 x 105 x 140 mm
