PT-7728 User’s Manual Featured Functions
3-6
Setting Description Factory Default
Enable This enables flow control for this port when the
port's Speed is set to Auto.
Disable
Disable This disables flow control for this port when the
port's Speed is set to Auto.
MDI/MDIX
Setting Description Factory Default
Auto This allows the port to auto-detect the port type of
the connected Ethernet device and change the
port type accordingly.
Auto
MDI Choose MDI or MDIX if the connected Ethernet
device has trouble auto-negotiating for port type.
MDIX
Network
The Network configuration allows users to configure both IPv4 and IPv6 parameters for
management access over the network. This Moxa Ethernet switch supports both IPv4 and IPv6,
and can be managed through either of these address types. An explanation of each configuration
item follows.
IPv4
The IPv4 settings include the switch’s IP address and subnet mask, as well as the IP address of the
default gateway. In addition, input cells are provided for the IP addresses of a 1st and 2nd DNS
server.
IPv6
The IPv6 setting includes two distinct address types: Link-Local Unicast address and Global
Unicast address. A Link-Local address makes the switch accessible over IPv6 for all devices
attached to the same local subnet. To connect to a larger network with multiple segments, the
switch must be configured with a Global Unicast address.
