PT-7728 User’s Manual Featured Functions
3-72
LLDP
The LLDP function is defined by IEEE 802.11AB, and is an OSI Layer 2 protocol that
standardizes the methodology of self-identity advertisement. It allows each networking device,
such as a Moxa managed switch, to periodically inform its neighbors about its self-information
and configurations. As a result, all such devices will have information about their neighbors, and
by using SNMP, this knowledge can be transferred to Moxa’s MXview for auto-topology and
network visualization purposes.
Enable LLDP
Setting Description Factory Default
Enable or Disable Enable or disable LLDP function. Enable
Value
Setting Description Factory Default
5 to 32768 Transmit interval of LLDP messages, in seconds. 30 (seconds)
LLDP
Setting Description Factory Default
Enable/Disable Enable or disable LLDP function Enable
Message Transmit Interval
Setting Description Factory Default
5 to 32768 Transmit interval of LLDP messages, in seconds. 30 (seconds)
