PT-7728 User’s Manual Specifications
C-9
0x3683 1 word TR2 Ring 2 2nd Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Ring 2 Not Enable
Memory mapping from address 0x0000 ~ 0x3FFF.
Modbus Information
Read Only Registers (Support Function Code 4) 1 Word = 2Bytes
Address Data Type Description
System Information
0x0000 1 word Vendor ID = 0x1393
0x0001 1 word Unit ID (Ethernet = 1)
0x0002 1 word Product Code = 0x0009
0x0010 20 word
Vendor Name = “Moxa”
Word 0 Hi byte = ‘M’
Word 0 Lo byte = ‘o’
Word 1 Hi byte = ‘x’
Word 1 Lo byte = ‘a’
Word 2 Hi byte = ‘\0’
Word 2 Lo byte = ‘\0’
0x0030 20 word
Product Name = “PT-7728”
Word 0 Hi byte = ‘P’
Word 0 Lo byte = ‘T’
Word 1 Hi byte = ‘-’
Word 1 Lo byte = ‘7’
Word 2 Hi byte = ‘7’
Word 2 Lo byte = ‘2’
Word 3 Hi byte = ‘8’
Word 3 Lo byte = ‘\0’
Word 4 Hi byte = ‘\0’
Word 4 Lo byte = ‘\0’
0x0050 1 word Product Serial Number
0x0051 2 word
Firmware Version
Word 0 Hi byte = major (A)
Word 0 Lo byte = minor (B)
Word 1 Hi byte = release (C)
Word 1 Lo byte = build (D)
0x0053 2 word
Firmware Release Date
Firmware was released on 2007-05-06 at 09 o’clock
Word 0 = 0x0609
Word 1 = 0x0705
