PT-7728 User’s Manual Specifications
C-10
0x0055 3 word
Ethernet MAC Address
Ex: MAC = 00-01-02-03-04-05
Word 0 Hi byte = 0x00
Word 0 Lo byte = 0x01
Word 1 Hi byte = 0x02
Word 1 Lo byte = 0x03
Word 2 Hi byte = 0x04
Word 2 Lo byte = 0x05
0x0058 1 word
Power 1
0x0000:Off
0x0001:On
0x0059 1 word
Power 2
0x0000:Off
0x0001:On
0x005A 1 word
Fault LED Status
0x0000:No
0x0001:Yes
0x0080 1 word
DI1
0x0000:Off
0x0001:On
0x0081 1 word
DI2
0x0000:Off
0x0001:On
0x0082 1 word
DO1
0x0000:Off
0x0001:On
0x0083 1 word
DO2
0x0000:Off
0x0001:On
Port Information
0x1000~0x1011 1 word Port 1~18 Status
0x0000:Link down
0x0001:Link up
0x0002:Disable
0xFFFF:No port
