PT-7728 User’s Manual Featured Functions
3-66
Port Events Warning e-mail is sent when…
Link-ON The port is connected to another device.
Link-OFF
The port is disconnected (e.g., the cable is pulled out,
or the opposing device shuts down).
Traffic-Overload
The port’s traffic surpasses the Traffic-Threshold for
that port (provided this item is Enabled).
Traffic-Threshold (%)
Enter a nonzero number if the port’s Traffic-Overload
item is Enabled.
Traffic-Duration (sec.)
A Traffic-Overload warning is sent every
Traffic-Duration seconds if the average
Traffic-Threshold is surpassed during that time
period.
NOTE
The Traffic-Overload, Traffic-Threshold (%), and Traffic-Duration (sec) Port Event items
are related. If you Enable the Traffic-Overload event, then be sure to enter a nonzero
Traffic-Threshold percentage, as well as a Traffic-Duration between 1 and 300 seconds.
Override relay alarm settings
Click the checkbox to override the relay warning setting temporarily. Releasing the relay output
will allow administrators to fix any problems with the warning condition.
Warning List
Use this table to see if any relay alarms have been issued.
Using Line-Swap-Fast-Recovery
The Line-Swap Fast Recovery function, which is enabled by default, allows PT-7728 to return to
normal operation extremely quickly after devices are unplugged and then re-plugged into different
ports. The recovery time is on the order of a few milliseconds (compare this with standard
commercial switches for which the recovery time could be on the order of several minutes). To
disable the Line-Swap Fast Recovery function, or to re-enable the function after it has already
been disabled, access either the Console utility’s Line-Swap recovery page, or the Web Browser
interface’s Line-Swap fast recovery page, as shown below.
Configuring Line-Swap Fast Recovery
