4. Insert the temperature sensor into the large screw connection and turn it
to the desired position together with the capillary line. Tighten the small
screw connection of the thermometer sensor.
Figure19: Inserting and securing the temperature sensor
When using the offshore variant of the temperature sensor
(No.6 VA), be aware of the wrench sizes and torque specifica-
tions that deviate [►Section 12.3, Page 111] from the stan-
dard variant.
