To Abort Calibration:
1. Wait until AC displays. Calibration cannot be aborted when (--) is flashing.
2. Press the Mode button and hold it for approximately 5 seconds. Release the but ton
when the calibration level displays.
3. The channel returns to normal operation.
3.7 Setup and Setup Check Modes
The Setup Check mode allows the operator to view the selected options for t he m odul e
without allowing any changes to be made. Once this mode has been entered, the module
automatically displays each of the selected options for a short period of time and t hen it
returns to normal operation. The Setup mode allows the operator to change the operating
parameters by making choices for selected options.
The Setup Check & Setup modes display identical inf ormation with the f ollowing
exceptions:
• The Setup Check mode allows the user to view the operating parameters of the
channel, whereas the Setup mode allows the user to change these parameters.
• Entering the optional password is only available in the Setup mode.
NOTE: The Setup and Setup Check modes cannot be entered if the unit is in alarm or
f ault.
During the Setup mode the operator is allowed to select options. The selection procedure
is the same f or most of the options. Pressing the Mode button toggles the available
choices. When the display has indicated a choice for five consecutive seconds, without
the operator pressing the Mode button, the setup routine accepts that selection and
moves on to the next option available.
NOTE: Bef ore entering the Setup mode to make changes, the user s hould f i ll out the
Setup Mode Selection Table (Section 3.8). This aids the user during the selection
process in the Setup mode.
The Password, the High & Low Alarm set points, and the Calibration Level options of fer
the operator more than two choices. While these options are being selected, pressing the
Mode button repeatedly sequences the display to the next available choice f or that
option.
To enter the Setup Check mode:
1. Press and hold the Mode button until the SETUP LED begins flashing (about twenty
seconds).
2. When the SETUP LED is f lashing, release the Mode button to enter the Setup
Check mode.
To enter the Setup mode:
