3.8 Setup Mode Selection Table
This section helps the operator make selections during the Setup mode. It is
recommended that the operator fill-in the selections in the proper blanks and then use
this page as a ref erence while programming the Model 610A. The t ab le s hown bel ow
indicates the order of options in the Setup mode. To the ri ght of the option entry is a
description of the choices that are available for that option.
OPTION DESCRIPTION
ENTER
SELECTION
Password Enter the Password, if the Password is enabled
High Alarm
Options
Set the Energized (En) / De-Energized (dE) Option
Set the Latching (LA) / Non-Latching (nL) Option
Set the High alarm set point (from Low alarm set
point to 60, in increments of 5)
Low Alarm
Options
Set the Energized (En) / De-Energized (dE) Option
Set the Latching (LA) / Non-Latching (nL) Option
Set the Low alarm set point (from 10 to the High
alarm set point
Calibration
Level
Set the calibration level, LEL (from 25 to 90, in
increments of 1)
Password
Options
Set the Password to be Disabled (Pd) or Enabled
(PE)
If the Password option to be changed from
Disabled to Enabled:
Set the password digits
Lef t__________
Right__________
Table 7: Setup Display Options
