34
Operation
4.2.1
Instrument Settings
The following settings are saved to the device memory and will not change if the sensor type is
changed.
(1)
Scroll to Settings.
(2)
Select Instrument.
(3)
Select to enter the menu.
Setting Default Menu 1 Options Menu 2 Options
Analog Settings
(see Tab. 13)
Custom 1
(see Tab. 13)
3.5mA with HART
1.25mA with HART
Custom 1
Custom 2
Custom Settings
Calibration
Cleaning mode
1
Fault
Maintenance
Bluetooth Enabled Bluetooth Status
Reset All
Min/Max/Avg 1h
Interval (1h, 8h, 24h)
Start Hour (0-23h)
Swap Delay Enabled
Enable
Disable
Enable
Disable
Reset All
Set Date
UTC-5
(Factory Date and
Time)
Year (2000-2999)
Month (Jan-Dec)
Day (0-31)
Time (0:00-23:59)
Password
Disabled 0000-9999,
incr. 0001
Controller Data Reset N/A Controller Data Reset
Display Units
Sensor Dependent
(see Tab. 14)
PPM
mg/m
3
µMol
%Vol
Tag #
Blank Only configurable via
HART and Bluetooth
Reset Main Unit N/A Reset Main Unit
Tab. 12 Default Device Settings
1
Cleaning mode not available
US
