MSA ULTIMA X5000 User Manual

3.4.7 2"(50.8mm)PipeMount
Theintegratedmountingtabsonthedevicehousingcanbemountedtoa2"(50,8mm)pipeusingastandardU-bolt.MSA
providesU-boltsasanoptionalaccessory(PartNumber10179873),howeverany2”(50.8mm)pipeU-boltratedforthe
weightanddimensionsoftheULTIMA

X5000canbeused.
Figure 17 2" Pipe Mount with U-Bolt
3.4.8 AdjustablePipeMount
AUniversalPipeMountKit(P/N10176946)canbeusedtomounttheULTIMAX5000onpipesrangingfrom1-6”(20-150
mm)indiameter.Twobracketsaremountedovertopoftheintegratedmountingtabsandfittedwithanadjustablepipeband
(notincluded).
Figure 18 Adjustable Pipe Mount
19 Ultima X5000 Gas Monitor US
3 Installation

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
