3-14
MS-6728 ATX Mainboard
CAS# Latency
This controls the timing delay (in clock cycles) before SDRAM starts
a read command after receiving it. Settings: 2, 2.5 (clocks). 2 (clocks)
increases the system performance the most while 2.5 (clocks) provides
the most stable performance.
RAS# Precharge
This item controls the number of cycles for Row Address Strobe
(RAS) to be allowed to precharge. If insufficient time is allowed for
the RAS to accumulate its charge before DRAM refresh, refresh may
be incomplete and DRAM may fail to retain data. This item applies
only when synchronous DRAM is installed in the system. Available
settings: 2 clocks, 3 clocks, 4 clocks.
RAS# to CAS# Delay
When DRAM is refreshed, both rows and columns are addressed
separately. This setup item allows you to determine the timing of the
transition from RAS (row address strobe) to CAS (column address
strobe). The less the clock cycles, the faster the DRAM performance.
Setting options: 2 clocks, 3 clocks, 4 clocks, .
Precharge Delay
This setting controls the precharge delay, which determines the timing
delay for DRAM precharge. Settings: 5 clocks, 6 clocks, 7 clocks,
8clocks, .
Burst Length
This setting allows you to set the size of Burst-Length for DRAM.
Bursting feature is a technique that DRAM itself predicts the address
of the next memory location to be accessed after the first address is
accessed. To use the feature, you need to define the burst length,
which is the actual length of burst plus the starting address and
allows internal address counter to properly generate the next memory
location. The bigger the size, the faster the DRAM performance.
Available settings: 4, 8.
AGP Aperture Size (MB)
This setting controls just how much system RAM can be allocated to AGP for
video purposes. The aperture is a portion of the PCI memory address range
