USER MANUAL V1.0 | Updated January 19, 2019 35
String
Insert a string of data into messages.
From the Settings menu, use the arrow keys to go to String and press Enter. Input your strings
into the input section. Press ESC to apply and go back to the main menu.
NOTES:
Maximum length of each string is 50 characters.
Machine allows maximum 5 strings on the machine memory.
Random Jet
Schedule automatic jetting to clean the print head.
From the Settings menu, use arrow keys to select Random Jet and press Enter. Select Status
and press Enter.
Select Enable and input time for jetting (second (s)) at Time.
Select Disable to disable random jetting.
NOTES:
• Time for jetting varies from 10 to 60.000 seconds.
• This function is useful for Solvent base ink. So we recommend that, any user need enable
this function with time around 15-30 seconds to help printing quality.
Print Side
Set nozzles on 2 modes Manual and Auto.
From the Settings menu, use the arrow keys to go to Print Side and press Enter. Select Manual
or Auto by pressing Enter at Select.
Manual: Press Enter at Value to select Odd or Even. This is applied in case one of your
nozzle side is not working. Press Enter to apply.
Auto: Input the number that the nozzles will switch after certain prints. To automatically
switch nozzles after every print, input 1. To switch nozzles after every 25 prints, input 25.
NOTES:
Value input varies from 1 to 50.000 times.
Operation with PC: Odd and Even to achieve max 600x600dpi.
Operation with wireless keyboard: Odd or Even (max 300x300dpi).
Operation with smart devices: Odd or Even (max 300x300dpi).
Sensor
Select External or Internal sensor.
From the Settings menu, use the arrow keys to go to Sensor and press Enter. Move to your
desired mode and press Enter to confirm.
Direction
Set print direction correlating the direction of the conveyor. Machine supports 4 directions:
: left right, : right left, : reverse left right, : reverse right left.
From the Settings menu, use the arrow keys to go to Direction and press Enter. Move to your
desired direction and press Enter to confirm.
