Muller 6609d - Operating the Machine; The Operating Terminal; Introduction to the Operation of the Machine

Mod. 6609d-6612d: Automatic Forms Cutter 13.12.2006
-13-
Operator Level
Technician LevelProgramming Level
New programs are always entered in PROG 00
3. Operating the machine
The operation of the machine is divided into three levels:
Areas which are not intended for the operator are protected by special access options.
On the programming level all function parameters of the paper cutting machine can be accessed and programs can
be set up and saved.
The technician level operates in an additionally protected area. Service routines can be started. Info rmation about the
condition of the machine can be read.
3.1 The operating terminal
The operating terminal is on the right-hand side of the machine.
On this terminal are:
4 large buttons PROG, INFO, START and STOP, two LEDs each containing 2 lines for 20 character s, and 4 small
multifunction buttons F1-F4. The functions of these buttons are always shown in the lower display.
3.1.1 Introduction to the operation of the machine
Explanation of terms
Parameter Before forms can be cut, a number of different values have to be set, such as sheet length,
type of cut or speed. These values are called parameters.The parameters are entered via
the terminal.
program A program consists of several parameters. The programs are saved in the terminal. Up to
100 programs can be saved. The programs saved are numbered continuously from 00 - 99.
Program structure Imagine the arangement of the programs, each with its individual parameters, like a card file.
Each program represents one index card. The individual parameters are recorded on the
index card.
Program In program selection mode, any program that has been saved can be selected.
selection mode To do this the "function buttons” F1, F2, F3, und F 4 are used. When the desired program
appears on the upper left display, the machine can be started by pressing the Start button.
The slots for working programs are numbered from >01< to >99<.
Parameter mode Parameter mode can be called from program selection mode by pressing the Prog button.
In parameter mode two basic functions can be selected:
1. Parameter selection mode
2. Parameter input mode
