Mod. 6609d-6612d: Automatic Forms Cutter 13.12.2006
-41-
3.3.3 Counter function ONLINE # 00 / # 01
The preset counter can be programmed to output any online functions. No OMR system is required (i.e. no reading
head). The reading head is automatically dead. Two or three functions can be carried out, one function several times,
the other(s) only once.
First the following information must be entered in the programming level:
1. Set the preset counter under parameter d) Counter.
2. Enter the function ONLINE #00/#01 under parameter e) Counter function.
3. Change into the service routine by pressing INFO and then PROG:
Service nr. 096: 2 Online functions (installed).
Service nr. 097: 3 Online functions (select when needed).
4. Select service nr. 008 and program the routine.
In an OMR routine desired functions are programmed in the first two lines # 00 / # 01 of the list (input in the CODE
column is of no significance).
2 ONLINE functions
The machine carries out the function entered under line #01 until the number before the preset number on the counter
is reached. On reaching the preset number, the mach ine carries out the function entered under line #00 . At the same
time the actual counter returns to 00000.
Example:
Example: In OMR program 2, three forms are to be collected and enveloped.
1. Select service no. 008 and enter OMR routine 2.
2. Press F4.
3. In line # 00 enter 00001 (enveloping) for the function.
4. Use F3 to switch between Code and Fnc.
5. In line # 01 enter 00002 (collect) for the function.
To return to program press the Prog-button twice and call service nr. 000.
Routine 2 Code Function
# 00 00000 00001 (enveloping) Sheet 00003
# 01 00000 00002 (collect) Sheets 00001 to 00002
The program can be saved in any program slot from 01-84. The counter (PRESET + ACTUAL) can be changed from
programs 00-84.
Special cases: Preset 00001 - the function in # 00 will always be output.
Preset 00000 - the function in # 01 will always be output.
