Mod. 6609d-6612d: Automatic Forms Cutter 13.12.2006
-42-
Access to the technician level should be restricted to trained service technicians only.
3 ONLINE functions
The machine carries out the function entered under line #01 until two numbers before the preset number on the
counter is reached. Then the machine once carries out the function entered under line # 02. On reaching the preset
number, the machine once carries out the function e ntered under line #00. At the same time the actual counter returns
to 00000.
Example: In OMR program 2, four forms are to be collected and enveloped, one form will be deflected.
Routine 2 Code Function
# 00 00000 00004 (deflect) Sheet 00005
# 01 00000 00002 (collect) Sheets 00001 to 00003
# 02 00000 00001 (enveloping) Sheet 00004
3.4 The technician level (level 3)
In order to access the technician level the machine must first be switched off. Then switch the machine on while
holding down buttons F1-F4. When OK appears in the display, press INFO once. Then release F1-F4.
To get into the service routines press INFO and then PROG.
The technician has all the service facilities at his disposal.
When the machine is switched off, it returns automatically to the operator level.
F1 and F2 - Move one service no. up or down (R)
F1 and F2 together - Move fast through the service nos.
F3 - Select service no. 000
F4 - Start the selected service routine
