Muller 6609d - Block Deflect; Transversal Accumulator; Stream Stacking; Cut at Mark

Mod. 6609d-6612d: Automatic Forms Cutter 13.12.2006
-36-
Conversion Table 2: Convert function into 5-digit number
Function (Fnc)
5-digit number
Müller online equipment to be activated
00001 End of group, enveloping, stapling, eject
00002 Collect (Accumulator)
00004 Deflect (Deflector Unit 1), see a)
00008 Deflect (Deflector Unit 2), see a)
00016 Deflect (Deflector Unit 3), see a)
00032 Deflect (Deflector Unit 4), see a)
00064 Free (e.g. selective)
00128 Free (e.g. selective)
00256 Change direction (cross transport)
00513 Change direction (Transversal Accumulator), see b)
01024 Dual action (cross transport)
02048 Group will be stapled if digi-switch for staple reverse in staple
module 6760/6766 is set at position 5,6,7.
04096 Free
08192 Free
16384 Block Deflection, see a)
32768 Stop
a) Block Deflect:
Block Deflection can be performed by any Müller 6630 deflector unit. The hinged cover of the first def lector unit after
the cutting machine is opened by function 16384 and stays open until function 00001 = End of group is recognised.
In the same way, cross transport 6691 and block Deflection (function 16384) are activated until End of group (function
00001).
b)Transversal Accumulator:
For the Transversal Accumulator, function 00513 is: Eject group from machine.
(00512 for Change direction + 00001 for Eject).
c) Stream stacking:
Lengthwise group separation is obtained with functi on 00003 (00002 + 00001).
d) Cut at mark:
If you wish the machine to make a cut at a particular mark, first select OMR routine 7 and enter the definition for the
adjustment line "AL" (the "AL" triggers cutting).
