Muller 6609d - Messages

Mod. 6609d-6612d: Automatic Forms Cutter 13.12.2006
-48-
3.4.2 Messages
The messages appear from the following software version onwards:
Central computer chip "H ..... 46/92" ("H 133")
and display chip "D ..... 05/93"
Display after
switching on or
during
operation
Function Comments
007 ID chip ID chip missing or interface blocked
011 Opto 1 - Cross cutter Start service no. 011 (adj ust opto 1)
012 Opto 2 - Cross cutter Start service no. 012 (adjust opto 2)
013 Opto 3 - Tractor Start service no. 013 (adjust opto 3)
014 Opto 4 - Tractor Start service no. 014 (adjust opto 4)
021 Opto 1-2 Phase position Start service no. 021 (opto 1-2, phase position: adjust distance between the
two scanner heads)
022 2) Overcurrent at cross cutter motor Cause: Cross cutter is too stiff, motor is blocked, winding or final stage
is defective
023 Opto 3-4 Phase position Start service no. 023 (opto 3-4, phase position: adjust distance between the
two scanner heads)
024 2) Overcurrent at tractor motor Cause: Motor is blocked, winding or final stage is defective
025 2) Overcurrent at ejector motor Cause: Motor is blocked, winding or final stage is defective
026 Overcurrent at edge blade turbine motor Cause: Motor is blocked, winding or final stage is defective
031 2)
Opto 1 - Cross cutter
DA value outside permissible range
Cause: Dirt on encoder disk or fibre-optic
Distance at scanner head not correct
Fibre-optic not plugged in
Power supply interrupted
After correcting the problem, start service routine 10.
032 2)
Opto 2 - Cross cutter
033 2) Opto 3 - Tractor
034 2) Opto 4 - Tractor
040 8) Revolution - Controll Cause: Cross cutter is too stiff, motor is blocked, winding or final stage
is defective
099 7) Supplementary cooling fan defective The supplementary cooling fan for models 6611, 6612 and 6613 is tested with
a pressure sensor to check whether it is functioning correctly. If the pressure is
not sufficient, the interface to the terminal will be blocked. The message 099
Call Service!" will appear in the display. Operation cannot be continued, The
forms cutter must be switched off.
Cause: Defective motor, air distribution channel no t correctly installed, or motor
not plugged in.
2) Only for forms cutters with new main board (without pots.)
7) Only forms cutters 6611/6612, from display chip "D 16061 39/94" onward
8) Only for forms cutters with cross-cutter chip "Q .....08/00"
