Mod. 6609d-6612d: Automatic Forms Cutter 13.12.2006
-46-
Service
routine
no.
Function Display when a
service routine is
started
Comments
068 4)
069 4)
Start/Stop
Start/Stop
see service routine 9
table N
The Start/Stop button can be used during online operation.
The Start/Stop button cannot be used during online operation.
070 Find beginning of paper
automatically
OK
071 Position beginning of
paper manually
OK
074 4)
075 4)
Fine position normal
Fine position x2
see service routine 9
table N
In parameter h) Fine Position, the values entered will be used unaltered.
In parameter h) Fine Position, the values entered will be multiplied
by factor 2.
076 4)
077 4)
OMR intermediate
adjustment off
OMR intermediate
adjustment on
see service routine 9
table N
No intermediate stroke to adjust position of OMR marks.
After every 1024 strokes, one intermediate stroke to adjust position of OMR
marks when reader is being used.
078 5) Display darker 244-004
The language in the display can be changed by activating the appropriate
service routine.
079 5) Display brighter 004-244
080 5) Language: German 000
081 5) Language: English 001
082 5) Language: French 002
083 5) Language: Italian 003
084 5) Language: Dutch 004
085 5) Language: Portuguese 005
086 5) Language: Spanish 006
087 5) Language: Norwegian 007
088 5) Language: Japanese 008
089 5) Language: Swedish 009
090 5) Language: Czech 010
096
097
ONLINE function
ONLINE function
see service routine 9
table N
A maximum of two online functions can be performed with the counter.
maximum of three online functions can be performed with the counter.
098
099
Fine offset +1
Fine offset -1
After changing or replacement of the cross-cutter subassembly (comlete
block) the new cut-position has to be fine-adjusted again. The form is
positioned on the blade edge. When service routines 98 or 99 are started, the
distance between light barrier (paper recognition) and cut position is adjusted.
In parameter h) the fine position is correctly set at factor 00 atfer fine offset.
Fine offset +1: The distance from light barrier to cut position is increased by
factor 1 (corresponds to 1/192").
Fine offset -1: the distance from light barrier to cut position is decreased by
factor 1 (corresponds to 1/192").
100
101
Set board (PCB)
Set board without
temperature and
pressure sensor.
Set board (PCB)
Set latest board version
with temperature and
pressure sensor.
see service routine 9
table O
PCB version installed previously without control,
(for machines without fan for the motors, but with NEW PCB)
Newest board version with temperature and pressure sensor.
4) Only for Automatic Forms Cutter with central computer chip "H.....47/95"
5) From new display board 16060 onward.
