User Manual
3. Select Counter as ON or OFF in the right menu.
How to Save and Recall a Waveform
Push the Utility button, select Function in the right menu, select Save in the left menu.
By selecting Type in the right menu, you can save the waveforms, configures or screen
images.
When the Type is selected as Wave, the menu is shown as the following table:
Display the save function menu
Choose the saving type as wave.
Source
CH2
Math
All
Choose the waveform to be saved.
(Choose All
to save all the waveforms that
are t
urned on. You can save into the
current internal object address, or into USB
storage as a single file.)
Object
ON
OFF
The object Wave0 –Wave15 are listed in
the left menu, turn the M rotary control to
choose the object
saved to or recall from.
Recall or close the waveform stored in the
current object address.
ON, if the current object address has been
used, the stored waveform will be shown,
the address number and relevant
information will be displayed at the top left
of the screen; if the address is empty, it
will prompt "None is saved".
Close All
Close all the waveforms stored in the
object address.
File Format
TXT
For internal storage, only BIN can be
selected. For external sto
can be BIN, TXT or CSV.
Save
Save the waveform of the source to the
selected address.
Storage
Internal
External
Save to internal storage or USB storage.
When External is selected, the file name is
editable. The BIN waveform file could be
open by the waveform analysis software
When the Type is selected as Configure, the menu is shown as the following table:
